MOS INTEGRATED CIRCUIT

µPD720100A

USB 2.0 HOST CONTROLLER

Document No.

S15535EJ3V0DS00 (3rd edition)

Date Published March 2005 NS CP (K)

Printed in Japan

DATA SHEET

The mark

shows major revised points.

2001

The

µPD720100A complies with the Universal Serial Bus Specification Revision 2.0 and Open Host Controller

Interface Specification for full-/low-speed signaling and Intel's Enhanced Host Controller Interface Specification for

high-speed signaling and works up to 480 Mbps. The

µPD720100A is integrated three host controller cores with PCI

interface and USB 2.0 transceivers into a single chip.

Detailed function descriptions are provided in the following user’s manual. Be sure to read the manual before designing.

µPD720100A User’s Manual: S15534E

FEATURES

•

Compliant with Universal Serial Bus Specification Revision 2.0 (Data Rate 1.5/12/480 Mbps)

•

Compliant with Open Host Controller Interface Specification for USB Rev 1.0a

•

Compliant with Enhanced Host Controller Interface Specification for USB Rev 0.95

•

PCI multi-function device consists of two OHCI host controller cores for full-/low-speed signaling and one EHCI

host controller core for high-speed signaling.

•

Root hub with five (max.) downstream facing ports which are shared by OHCI and EHCI host controller core

•

All downstream facing ports can handle high-speed (480 Mbps), full-speed (12 Mbps), and low-speed (1.5 Mbps)

transaction.

•

Configurable number of downstream facing ports (2 to 5)

•

32-bit 33 MHz host interface compliant to PCI Specification release 2.2.

•

Supports PCI Mobile Design Guide Revision 1.1.

•

Supports PCI-Bus Power Management Interface Specification release 1.1.

•

PCI Bus bus-master access

•

System clock is generated by 30 MHz X’tal or 48 MHz clock input.

•

Operational registers direct-mapped to PCI memory space

•

Legacy support for all downstream facing ports. Legacy support features allow easy migration for motherboard

implementation.

•

3.3 V power supply, PCI signal pins have 5 V tolerant circuit.

ORDERING INFORMATION

Part Number

Package

Remark

µPD720100AGM-8ED

160-pin plastic LQFP (Fine pitch) (24

× 24)

µPD720100AGM-8EY

160-pin plastic LQFP (Fine pitch) (24

× 24)

µPD720100AGM-8EY-A

160-pin plastic LQFP (Fine pitch) (24

× 24)

Lead-free product

µPD720100AS1-2C

176-pin plastic FBGA (15

× 15)

µPD720100AS1-2C-A

176-pin plastic FBGA (15

× 15)

Lead-free product
