Data Sheet S15535EJ3V0DS

12

µPD720100A

2.3

Electrical Specifications

Absolute Maximum Ratings

Parameter

Symbol

Condition

Rating

Unit

Power supply voltage

VDD

−0.5 to +4.6

V

AVDD

−0.5 to +4.6

V

VDD_PCI

−0.5 to +6.0

V

Input voltage, 5 V buffer

VI

3.0 V

≤ VDD ≤ 3.6 V

VI

< VDD + 3.0 V

−0.5 to +6.6

V

Input voltage, 3.3 V buffer

VI

3.0 V

≤ VDD ≤ 3.6 V

VI

< VDD + 0.5 V

−0.5 to +4.6

V

Output voltage, 5 V buffer

VO

3.0 V

≤ VDD ≤ 3.6 V

VO

< VDD + 3.0 V

−0.5 to +6.6

V

Output voltage, 3.3 V buffer

VO

3.0 V

≤ VDD ≤ 3.6 V

VO

< VDD + 0.5 V

−0.5 to +4.6

V

Operating temperature

TA

0 to

+70

°C

Storage temperature

Tstg

−65 to +150

°C

Caution Product quality may suffer if the absolute maximum rating is exceeded even momentarily for any

parameters. That is, the absolute maximum ratings are rated values at which the product is on the

verge of suffering physical damage, and therefore the product must be used under conditions

that ensure that the absolute maximum ratings are not exceeded.

The ratings and conditions indicated for DC characteristics and AC characteristics represent the

quality assurance range during normal operation.

Recommended Operating Ranges

Parameter

Symbol

Condition

MIN.

TYP.

MAX.

Unit

Operating voltage

VDD

3.0

3.3

3.6

V

AVDD

3.0

3.3

3.6

V

VDD_PCI

In 3.3 V PCI

3.0

3.3

3.6

V

In 5 V PCI

4.75

5.0

5.25

V

High-level input voltage

VIH

3.3 V High-level input voltage

2.0

VDD

V

5.0 V High-level input voltage

2.0

5.5

V

Low-level input voltage

VIL

3.3 V Low-level input voltage

0

0.8

V

5.0 V Low-level input voltage

0

0.8

V
