Data Sheet S15535EJ3V0DS

15

µPD720100A

Figure 2-1. Differential Input Sensitivity Range for Low-/full-speed

4.6

-1.0

Input Voltage Range (Volts)

Differential Input Voltage Range

Differential Output

Crossover

Voltage Range

0.0

0.2

0.4

0.6

0.8

1.0

1.2

1.4

1.6

1.8

2.0

2.2

2.4

2.6

2.8

3.0

3.2

Figure 2-2. Full-speed Buffer VOH/IOH Characteristics for High-speed Capable Transceiver

Max.

Min.

-80

-60

-40

-20

0

VDD-0.3

Vout (V)

VDD-2.3

VDD-3.3

VDD-0.8

VDD

VDD-1.3

VDD-1.8

VDD-2.8

Figure 2-3. Full-speed Buffer VOL/IOL Characteristics for High-speed Capable Transceiver

Max.

Min.

80

60

40

20

0

0

0.5

1

1.5

2

2.5

3

Vout (V)
