9 / 34 page  Data Sheet S15535EJ3V0DS 7 µPD720100A Pin No. Pin Name Pin No. Pin Name Pin No. Pin Name Pin No. Pin Name 1 VSS 45 VDD 89 SELCLK 133 PPON1 2 VSS 46 NTEST1 90 VSS 134 OCI4 3 SMC 47 NANDTEST 91 RSDM1 135 VSS 4 AD20 48 TEST 92 RSDP1 136 SCK/TCLK 5 AD18 49 VSS 93 DM2 137 PPON5 6 CBE20 50 IRI1 94 RSDP2 138 VSS 7 DEVSEL0 51 IRO2 95 AVSS 139 VDD 8 VDD_PCI 52 VBBRST0 96 PC2 140 RSDP5 9 SERR0 53 VDD 97 AVSS 141 VDD 10 VSS 54 INTA0 98 DM3 142 DP1 11 AD14 55 PIN_EN 99 DP3 143 VSS 12 AD11 56 REQ0 100 RSDM4 144 VDD 13 CBE00 57 AD29 101 DP4 145 VSS 14 AD6 58 AD25 102 VSS 146 AVDD 15 VSS 59 CBE30 103 VSS 147 N.C. 16 AD5 60 N.C. 104 VDD 148 RREF 17 N.C. 61 IDSEL 105 NTEST2 149 VSS 18 AD3 62 VSS 106 LEGC 150 VDD 19 VDD_PCI 63 AD23 107 VCCRST0 151 VSS 20 SRMOD 64 AD22 108 IRI2 152 DM4 21 OCI5 65 AD19 109 A20S 153 XT1/SCLK 22 OCI3 66 AD17 110 PCLK 154 XT2 23 VDD 67 FRAME0 111 INTC0 155 VDD 24 PPON3 68 TRDY0 112 AD31 156 SMI0 25 TEB 69 CBE10 113 VSS 157 IRO1 26 VSS 70 AD13 114 AD27 158 PME0 27 DM5 71 AD12 115 AD24 159 VSS 28 VSS 72 AD9 116 VDD 160 INTB0 29 N.C. 73 AD7 117 SIN/TIN 161 GNT0 30 N.C. 74 VSS 118 SOT/TOUT 162 AD30 31 VSS 75 VSS 119 AD21 163 AD28 32 N.C. 76 VDD 120 VDD 164 AD26 33 DM1 77 AD4 121 AD16 165 VSS 34 RSDM2 78 AD0 122 IRDY0 166 VDD 35 DP2 79 SRDTA 123 STOP0 167 PERR0 36 VDD 80 OCI1 124 PAR 168 VSS 37 AVSS 81 OCI2 125 AD15 169 VSS 38 PC1 82 AMC 126 VDD 170 PPON2 39 AVSS (R) 83 PPON4 127 AD10 171 VSS 40 VDD 84 CLKSEL 128 AD8 172 VSS 41 RSDM3 85 RSDM5 129 AD2 173 AVDD 42 RSDP3 86 DP5 130 AD1 174 VSS 43 N.C.(VDD) 87 SELDAT 131 CRUN0 175 VDD 44 RSDP4 88 VDD 132 SRCLK 176 VDD_PCI Remarks 1. Pin 43 can be opened. But this signal is connected to pin 45 in the package. Should not be connected to GND. 2. AVSS (R) should be used to connect RREF through 1 % precision reference resistor of 9.1 k Ω. |
|
