CC1110

CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A

Page 111 of 202

T3CCTL0 (0xCC) – Timer 3 Channel 0 Capture/Compare Control

Bit

Name

Reset

R/W

Description

Unused

R/W

Channel 0 interrupt mask

0 : interrupt is disabled

1 : interrupt is enabled

Channel 0 compare output mode select. Specified action on output

when timer value equals compare value in

T3CC0

000

Set output on compare

001

Clear output on compare

010

Toggle output on compare

011

Set output on compare-up, clear on 0 (clear on compare-

down in up/down mode)

100

Clear output on compare-up, set on 0 (set on compare-

down in up/down mode)

101

Set output on compare, clear on 0xFF

110

Clear output on compare, set on 0x00

5:3

CMP[2:0]

000

R/W

111

Not used

Mode. Select Timer 3 channel 0 capture or compare mode

Capture mode

MODE

R/W

Compare mode

Channel 0 capture mode select

No capture

Capture on rising edge

Capture on falling edge

1:0

CAP[1:0]

R/W

Capture on all edges

T3CC0 (0xCD) – Timer 3 Channel 0 Capture/Compare Value

Bit

Name

Reset

R/W

Description

7:0

VAL[7:0]

0x00

R/W

Timer capture/compare value channel 0
