CC1110

CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A

Page 113 of 202

T4CTL (0xEB) – Timer 4 Control

Bit

Name

Reset

R/W

Description

Prescaler divider value. Generates the active clock edge used to

clock the timer from

CLKCON.TICKSPD as follows:

000

Tick frequency /1

001

Tick frequency /2

010

Tick frequency /4

011

Tick frequency /8

100

Tick frequency /16

101

Tick frequency /32

110

Tick frequency /64

7:5

DIV[2:0]

R/W

111

Tick frequency /128

START

R/W

Start timer. Normal operation when set, suspended when cleared

OVFIM

R/W0

Overflow interrupt mask

CLR

R0/W1

Clear counter. Writing high resets counter to 0x00

Timer 4 mode. Select the mode as follows:

Free running, repeatedly count from 0x00 to 0x00

Down, count from T4CC0 to 0x00

Modulo, repeatedly count from 0x00 to T4CC0

1:0

MODE[1:0]

R/W

Up/down, repeatedly count from 0x00 to T4CC0 and down

to 0x00
