Tektronix Next Generation Oscilloscopes

2 Series MSO

3 Series MDO

4 Series MSO

5 Series B MSO

6 Series B MSO

Compact, portable, battery-

operated instrument

Extreme versatility for any

bench

Up to 6 channels of high-

visibility bench test

Advanced analysis and up to 8

inputs

Unmatched detail on high-

speed signals

Compact, versatile oscilloscope for daily debug

The 2 Series MSO features up to 4 analog channels, 500 MHz

bandwidth, 2.5 GS/s sample rate, 16 channel MSO, 50 MHz AFG, 4-bit

digital pattern generator, advanced triggers, protocol decode, DVM, and

frequency counter is packed with features, all in a compact form factor

about 1.5” thick making it the go-to oscilloscope for electronic debug

and test, no matter where you work.

With a capacitive touchscreen and a highly intuitive user interface truly

designed for touch, the 2 Series MSO joins the Tektronix family of

award-winning next generation oscilloscopes. The shared user interface

and the programmatic interface makes it easy to use any Tektronix next

generation oscilloscope

The optional battery pack extends the instrument capabilities by

enabling the same instrument that is used in the lab to also be used in

the field.

A large catalog of compatible probes and well-rounded set of

accessories makes the 2 Series MSO the most capable and versatile

instrument in its class and suitable for a variety of applications.

Intuitive touchscreen with simplified front panel

The 2 Series MSO offers the same, award-winning user interface as on

the higher end Tektronix oscilloscopes and supports touch-interactions

that you have come to expect in a touch-enabled consumer device.

2 Series MSO Datasheet
