7.1. GPIO Ports

The 16 GPIO pins are grouped into three ports: PA, PB, and PC. Individual GPIOs within a port are numbered 0 to

7 according to their bit positions within the GPIO registers.

Note: Because GPIO port registers’ functions are identical, the notation Px is used here to refer to PA, PB, or PC. For example,

GPIO_PxIN refers to the registers GPIO_PAIN, GPIO_PBIN, and GPIO_PCIN.

Each of the three GPIO ports has the following registers whose low-order eight bits correspond to the port’s eight

GPIO pins:



GPIO_PxIN (input data register) returns the pin level (unless in analog mode).



GPIO_PxOUT (output data register) controls the output level in normal output mode.



GPIO_PxCLR (clear output data register) clears bits in GPIO_PxOUT.



GPIO_PxSET (set output data register) sets bits in GPIO_PxOUT.



GPIO_PxWAKE (wake monitor register) specifies the pins that can wake the EM346.

In addition to these registers, each port has a pair of configuration registers, GPIO_PxCFGH and GPIO_PxCFGL.

These registers specify the basic operating mode for the port’s pins. GPIO_PxCFGL configures the pins Px[3:0]

and GPIO_PxCFGH configures the pins Px[7:4]. For brevity, the notation GPIO_PxCFGH/L refers to the pair of

configuration registers.

Two GPIO pins (PA7 and PC0) can sink and source higher current than standard GPIO outputs. Refer to Table 2.5

Digital I/O Specifications in "2. Electrical Specifications" on page 7 for more information.

7.2. Configuration

Each pin has a 4-bit configuration value in the GPIO_PxCFGH/L register. The various GPIO modes and their 4-bit

configuration values are shown in Table 7.1.

If a GPIO has two peripherals that can be the source of alternate output mode data, then other registers in addition

to GPIO_PxCFGH/L determine which peripheral controls the output.

If a GPIO does not have an associated peripheral in alternate output mode, its output is set to 0.

For outputs assigned to the serial controllers, the serial interface mode registers (SCx_MODE) determine how the

GPIO pins are used. The alternate outputs of PA4 and PA5 can either provide packet trace data (PTI_EN and

PTI_DATA) or synchronous CPU trace data (TRACEDATA2 and TRACEDATA3). The selection of packet trace or

CPU trace is made through the Ember software.

Table 7.1. GPIO Configuration Modes

GPIO Mode

GPIO_PxCFGH/L

Description

Analog

0x0

Analog input or output. When in analog mode, the digital input (GPI-

O_PxIN) always reads 1.

Input (floating)

0x4

Digital input without an internal pull up or pull down. Output is disabled.

Input (pull-up or

pull-down)

0x8

Digital input with an internal pull up or pull down. A set bit in GPIO_Px-

OUT selects pull up and a cleared bit selects pull down. Output is dis-

abled.

Output (push-pull)

0x1

Push-pull output. GPIO_PxOUT controls the output.

Output (open-

drain)

0x5

Open-drain output. GPIO_PxOUT controls the output. If a pull up is

required, it must be external.

Alternate Output

(push-pull)

0x9

Push-pull output. An onboard peripheral controls the output.

Alternate Output

(open-drain)

0xD

Open-drain output. An onboard peripheral controls the output. If a pull

up is required, it must be external.
