Q-Series

AC 100V

AC 120V

AC 230V

Efficiency

typ.

90.4%

91.4%

92.0%

at 3.8A

Average efficiency *)

typ.

89.4%

90.0%

90.0 %

25% at 0.95A, 25% at 1.9A,

25% at 2.85A. 25% at 3.8A

Power losses

typ.

3.7W

3.8W

4.3W

at 0A

typ.

9.7W

8.6W

7.9W

at 3.8A

*)

The average efficiency is an assumption for a typical application where the power supply is loaded with 25% of the nominal load for 25%

of the time, 50% of the nominal load for another 25% of the time, 75% of the nominal load for another 25% of the time and with 100%

of the nominal load for the rest of the time.

Fig. 9-1

Efficiency vs. output current, typ

Fig. 9-2

Losses vs. output current, typ.

Efficiency

0.5

1.5

1.0

2.0

2.5

4A

85

86

87

88

89

90

Output Current

91

92

93%

120Vac

100Vac

230Vac

3.0

3.5

Power Losses

0

0.5

1

1.5

2

2.5

3

3.5

4A

0

2.5

5

7.5

10W

120Vac

100Vac

230Vac

Output Current

Fig. 9-3

Efficiency vs. input voltage at 3.8A,

typ.

Fig. 9-4

Losses vs. input voltage at 3.8A, typ.

Efficiency

85

120

155

190

225 260Vac

89

90

91

Input Voltage

92

93%

Power Losses

6

7

8

9

10

11

12W

85

120

155

190

225 260Vac

Input Voltage
