FT260 HID-CLASS USB TO UART/I2C BRIDGE IC

Version 1.1

Document No.: FT_001272 Clearance No.: FTDI#484

5.2

I2C Bus Interface

I2C (Inter Integrated Circuit) is a multi-master serial bus invented by Philips. I2C uses two bi-directional

open-drain wires called serial data (SDA) and serial clock (SCL). Common I²C bus speeds are standard

mode (SM) with a bit rate up to 100 Kbit/s, fast mode (FM) with a bit rate up to 400 Kbit/s, Fast mode

plus (FM+) with a bit rate up to 1 Mbit/s, and High Speed mode (HS) with the bit rate up to 3.4 Mbit/s.

An I2C bus node can operate either as a master or a slave:



Master node

– issues the clock and addresses slaves



Slave node

– receives the clock line and address.

The FT260 operates as an I2C master and is capable of being set to the speed modes defined in the I2C

bus specification. Besides the speed mode defined in the I2C standard specification, the I2C controller of

the FT260 can support flexible SCL frequencies defined by the following function

�� =

��

��∗(��+��)

�� = �� ; �� = ��, ��, ��, … … , ��

When the target frequency is below 100 KHz or higher than 1MHz, M will be equal to 8; otherwise, M will

be equal to 6. For example, to generate a 3MHz frequency on SCL, M will be selected as 8. With the

operating clock frequency equal to 48MHz, the user can set N as 1. The SCL frequency of the I2C master

mode for the FT260 can be set via USB commands. Details can be referenced in the FT260 Application

Notes.

5.2.1 I2C Pin Definition

The I2C function in the FT260 is an I2C master device. It is enabled by default when the FT260 is powered

up and the operating speed on the I2C bus is designed as 60 KHz for connectivity to most of the external

I2C slave devices. The I2C pins of the FT260 are



Clock – SCL (DIO5, pin 12 @ WQFN28), as clock output with open-drain design



Data

– SDA (DIO6, pin 13 @ WQFN28), command/address/data transfer between master and

slave with open-drain design

5.2.2 I2C Bus Protocol

There are four potential modes of operation for a given bus device, although most devices only use a

single role (Master or Slave) and its two modes (Transmit and Receive):



Master transmit – sending data to a slave



Master receive – receiving data from a slave



Slave transmit – sending data to a master



Slave receive

– receiving data from the master
