FT313HP-R datasheet(10/67 Pages) FTDI

10 / 67 page

Document No.: FT_000589

FT313H USB2.0 HS Host Controller Datasheet Version 1.2

Clearance No.: FTDI# 318

3.4 Pin Description

Pin No.

Name

Type

Description

AGND

Analog Ground

AD0

I/O

Bit 0 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

AD1

I/O

Bit 1 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

AD2

I/O

Bit 2 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

AD3

I/O

Bit 3 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

VCC(I/O)

I/O supply voltage; connect a 0.1uF decoupling

capacitor

1.8V, 2.5V or 3.3V

AD4

I/O

Bit 4 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

AD5

I/O

Bit 5 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

AD6

I/O

Bit 6 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

AD7

I/O

Bit 7 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

AD8

I/O

Bit 8 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

AD9

I/O

Bit 9 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

AD10

I/O

Bit 10 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

AD11

I/O

Bit 11 of the address and data bus

Bidirectional pad; push-pull, three-state output. 3.3V

tolerant

VCC(I/O)

I/O supply voltage; connect a 0.1uF decoupling

capacitor
