FT313HP-R 数据表(PDF) 48 Page - Future Technology Devices International Ltd. |
|
|
|||||||||||||||||||||||||||||
FT313HP-R 数据表(HTML) 48 Page - Future Technology Devices International Ltd. |
|
|
48 / 67 page  Copyright © 2013 Future Technology Devices International Limited 48 Document No.: FT_000589 FT313H USB2.0 HS Host Controller Datasheet Version 1.2 Clearance No.: FTDI# 318 NOR PIO timing characteristics (Ambient Temperature = -40°C to +85°C) Parameter Description VCC(I/O)=1.8V VCC(I/O)=2.5V VCC(I/O)=3.3V Unit Min Max Min Max Min Max Tch CS_N hold time after WR_N / RD_N high 0 - 0 - 0 - ns Tcsadval CS_N setup time before Address Latch 6.5 - 6.5 - 6 - ns Tah Address Hold Time after Address Latch 0 - 0 - 0 - ns Tas Address Setup Time before Address Latch 6 - 6 - 5 - ns Tap Address Latch Pulse Width 10 - 10 - 10 - ns Twc Write Cycle Time 80 - 78.5 - 78.5 - ns Twp WR_N Pulse Width 40 - 40 - 40 - ns Tdh RD_N High to Output Hi-Z 4 8 4 7 4 7 ns WR_N High to Input Hi-Z 0 - 0 - 0 - ns Tdadvh DATA Setup Time before DATA Latch 6 - 5 - 5 - ns Toe RD_N Low to DATA Output Enable 8 - 6 - 5 - ns Tbds Ready to WR_N/RD_N Low 5 - 5 - 5 - ns Trp RD_N Pulse Width 40 - 40 - 40 - ns Trc Read Cycle Time 80 - 79 - 79 - ns Table 6-11 NOR PIO timing |
|
