background image
Copyright © 2013 Future Technology Devices International Limited
46
Document No.: FT_000589
FT313H USB2.0 HS Host Controller Datasheet Version 1.2
Clearance No.: FTDI# 318
6.4 Timing
6.4.1 PIO timing
SRAM PIO timing characteristics (Ambient Temperature = -40°C to +85°C)
Parameter
Description
VCC(I/O)=1.8V
VCC(I/O)=2.5V
VCC(I/O)=3.3V
Unit
Min
Max
Min
Max
Min
Max
Tcs
CS_N setup time
before WR_N / RD_N
low
0
-
0
-
0
-
ns
Tch
CS_N hold time after
WR_N / RD_N high
0
-
0
-
0
-
ns
Tcp
CS_N pulse width for
read
40
-
40
-
40
-
ns
CS_N pulse width for
write
40
-
40
-
40
-
ns
Tasrw
address setup time
before WR_N / RD_N
low
0
-
0
-
0
-
ns
Tahrw
Address Hold Time
after WR_N/RD_N
LOW
0
-
0
-
0
-
ns
Tap
Address Latch Pulse
Width
ns
Twc
Write Cycle Time
80
-
79
-
78.5
-
ns
Twp
WR_N Pulse Width
40
-
40
-
40
-
ns
Tdh
RD_N High to Output
Hi-Z
4
9
4
7
4
6
ns
WR_N High to Input
Hi-Z
0
-
0
-
0
-
ns
Tdadvh
DATA Setup Time
before DATA Latch
6
-
6
-
6
-
ns
Toe
RD_N Low to DATA
Output Enable
8
-
7
-
6
-
ns
Trp
RD_N Pulse Width
40
-
40
-
40
-
ns
Trc
Read Cycle Time
80
-
79.5
-
79
-
ns
Table 6-10 SRAM PIO timing
