background image
Copyright © 2013 Future Technology Devices International Limited
41
Document No.: FT_000589
FT313H USB2.0 HS Host Controller Datasheet Version 1.2
Clearance No.: FTDI# 318
6.2 DC Characteristics
DC Characteristics (Ambient Temperature = -40°C to +85°C)
Parameter
Description
Minimum
Typical
Maximum
Units
Conditions
VCC(I/O)
VCCIO operating
supply voltage
1.62
1.8
1.98
V
Normal Operation
2.25
2.5
2.75
V
2.97
3.3
3.63
V
VCC(3V3)
VCC operating supply
voltage
2.97
3.3
3.63
V
Normal Operation
Icc1
Idle current
-
20
-
mA
Idle
Icc2
Operating current
-
35
-
mA
Normal Operation
High speed data
transfer
Icc3
USB suspend
-
200
-
uA
USB suspend
VCC(1V2)
Core supply voltage
1.08
1.2
1.32
V
Normal Operation
VOUT(1V2)
Internal 1.2V
regulator voltage
-
1.2
-
V
Normal Operation
Table 6-2 Operating Voltage and Current
Parameter
Description
Minimum
Typical
Maximum
Units
Conditions
Voh
Output Voltage High
2.4
3.3
-
V
Ioh=8mA
Vol
Output Voltage Low
-
-
0.4
V
Iol=8mA
Vih
Input High Voltage
2.0
-
-
V
-
Vil
Input Low Voltage
-
-
0.8
V
-
Vth
Schmitt Hysteresis
Voltage
0.3
0.45
0.5
V
-
Ipu
Input pull-up current
25
42
60
uA
Vin = 0V
Rpu
Input pull-up
resistance equivalent
120K
78K
60K
ohm
Vin = 0V
Ipd
Input pull-down
current
25
42
60
uA
Vin = VCC(I/O)
Rpd
Input pull-down
resistance equivalent
120K
78K
60K
ohm
Vin = VCC(I/O)
Iin
Input leakage current
-10
±1
10
uA
Vin = VCC(I/O) or
0
Ioz
Tri-state output
leakage current
-10
±1
10
uA
-
Table 6-3 Digital I/O Pin Characteristics (VCC(I/O) = +3.3V, Standard Drive Level)
