FT313HP-R 数据表(PDF) 20 Page - Future Technology Devices International Ltd. |
|
|
|||||||||||||||||||||||||||||
FT313HP-R 数据表(HTML) 20 Page - Future Technology Devices International Ltd. |
|
|
20 / 67 page  Copyright © 2013 Future Technology Devices International Limited 20 Document No.: FT_000589 FT313H USB2.0 HS Host Controller Datasheet Version 1.2 Clearance No.: FTDI# 318 5 Host controller specific registers 5.1 Overview of registers Table 5.1 shows the definitions of the FT313H host controller specific registers. Address Register Reset value Description EHCI operational register 00h HCCAPLENGTH 0100 0010h Capability register 04h HCSPARAMS 0000 0001h Structural parameter register 08h HCCPARAMS 0000 0006h Capability parameter register 10h USBCMD 0008 0B00h USB command register 14h USBSTS 0000 1000h USB status register 18h USBINTR 0000 0000h USB interrupt enable register 1Ch FRINDEX 0000 0000h Frame index register 24h PERIODICLISTADDR 0000 0000h Periodic frame list base address register 28h ASYNCLISTADDR 0000 0000h Current asynchronous list address register 30h POSTSC 0000 0000h Port status and control register Configuration register 34h EOFTIME 0000 0041h EOF time and asynchronous schedule sleep timer register 80h CHIPID 0313 0001h Chip ID register 84h HWMODE 0000 0000h HW mode control register 88h EDGEINTC 0000 001Fh Edge interrupt control register 8Ch SWRESET 0000 0000h SW reset register 90h MEMADDR 0000h Memory address register 92h DATAPORT 0000h Data port register 94h DATASESSION 0000h Data session length register 96h CONFIG 1FA0h Configuration register 98h AUX_MEMADDR 0000h Auxiliary memory address register 9Ah AUX_DATAPORT 0000h Auxiliary data port register 9Ch SLEEPTIMER 0400h Sleep timer register Interrupt register A0h HCINTSTS 0000h Host controller interrupt status register |
|
