30 / 60 page

www.knowlescapacitors.com

Part

Number

Cap Range

(pF)

Min. Q @

175 MHz

Dimensions

Fig.

52H01

52H02

1.5 to 10.0

>1400*

0.31

0.22

.295

.275

0.31

0.06

0.09

55H01

1.5 to 19.0

>1000

0.31

0.22

.295

.275

0.31

55H02

1.5 to 19.0

>1000

0.31

0.22

.295

.275

0.06

0.09

80H85

1.5 to 19.0

>1000

0.31

0.22

.295

.275

0.32

0.125

Notes: Dimensions (inches). *Q @ 195MHz.

High Voltage Trimmers

Characteristics



Rated voltage:

1250 VDC - test voltage 2500 VDC (52H02)

1000 VDC - test voltage 2000 VDC (55H01) (55H02) (80H85)



Q >1400@ 195 MHz (52H02)



Q >1000@ 175 MHz (55H01) (55H02) (80H85)



Insulation resistance: >106 MΩ



Operating temperature range: -65°C to +125°C



Torque: 1 to 10 oz. in.



Contact resistance: <.01 Ω

Figure 1

Figure 2

Figure 3

Recommended Tuning Tool

JMC 8764
