www.knowlescapacitors.com

Tuning Screw Torque Bushings

METAL (Fig.1)

Part No.

Thread

Mounting hole

(dia.)

LB1020-1

.145

.1247

.112

.030

.035

.130

#0(.060) -80

.1240/.1242

LB1021-1

.175

.1552

.140

.030

.035

.150

#2(.086) -56

1545/1547

LB1020-2

.1552

.140

.035

.130

#2(.086) -56

1545/1547

LB1022-1

.300

.2697

.250

.035

.090

.300

#4(.112) -40

.2690/.2692

LB1023-1

.330

.2997

.280

.035

.100

.335

#6(.138) -32

.2690/.2692

LB1023-2

.2997

.280

.100

.300

#6(.138) -32

.2690/.2692

LB1024-1

.380

.3497

.330

.035

.100

.335

#10(.190) -32

.3490/3492

LB1025-1

.440

.4097

.390

.035

.100

.335

¼(.250) -28

.4090/4092

LB1025-2

.4097

.390

.100

.300

¼(.250) -28

.4090/4092

LB1026-1

.350

.3197

.300

.035

.100

.335

#8(.164) -32

.3190/3192

Posi-torque Bushings are precision devices designed for applications

requiring precision, low loss high resolution tuning.

The self-locking, constant torque drive mechanism eliminates the

need for locking nuts and assures stable, noise free adjustment in

RF to Microwave frequencies.

Posi-Torque Bushings are universal and can be used with standard

SI and US customary screws.

THREAD

20º

REF

Ø C

Ø A

Ø B

+.0005

-.0000

+.000

-.015

SEE MOUNTING

HOLE DIA.
