Note: Other capacitance values may become available, please contact the Sales Office if you need values other than those shown in the above tables.

For dimensions and soldering information, please go to our website www.knowlescapacitors.com.

Reeled Quantities

Chip Size

0402

0505

0603

0805

1206

1111

1210

1808

1812

2220

2225

7” Reel

10000

2500

4000

3000

2500

10002000

1500

500

500

500

13” Reel

13” reel quantities available on request

6000

2000

2000

2000

Made from highly stable, low loss dielectric formulations, these

traditional porcelain MLCs are known for their high RF power

handling capability. Available in all industry common case sizes.

The special silver-palladium termination and the proprietary

ceramic formulations guarantee consistent non-magnetic

performance. All MLCs in these series are RoHS compliant. Chips

are available either with standard termination or can be fitted with

ribbon leads, depending on your application.

Description

• Porcelain Capacitors • Zero TC • Low Noise • Low ESR, High Q

• High Self-resonance • Established Reliability

• Capacitance range 0.1pF to 5.1nF

Functional Applications

• Impedance Matching • DC Blocking • Bypass • Coupling

• Tuning and Feedback

High Power RF capacitors - F & H materials - Minimum/maximum capacitance values

Chip Size

Case size 5

0505

Case size 11

1111

Case size 25

2225

Case size 38

3838

Min.

Max.

Min.

Max.

Min.

Max.

Min.

Max.

50V

-

-

680pF

1nF

-

-

-

-

100V

-

-

510pF

620pF

-

-

-

-

200V

36pF

100pF

220pF

470pF

-

-

-

-

250V

0.1pF

33pF

-

-

-

-

-

-

300V

-

-

-

-

2.2nF

2.7nF

-

-

500V

-

-

110pF

200pF

1.5nF

1.8nF

2.7nF

5.1nF

1kV

-

-

0.3pF

100pF

510pF

1.2nF

750pF

2.2nF

1.5kV

-

-

-

-

300pF

470pF

-

-

2kV

-

-

-

-

-

-

-

-

2.5kV

-

-

-

-

0.3pF

270pF

430pF

680pF

3.6kV

-

-

-

-

-

-

110pF

390pF

7.2kV

-

-

-

-

-

-

0.3pF

100pF

Note: Special capacitance values available upon request.

Non-Mag Caps, High Power RF - High Q

Ordering information - Non-Magnetic capacitors

11

470

J

1000

W

F

R

Chip size

Capacitance

Tolerance

Voltage

Termination

Material

Lead

5

11

25

38

0505

1111†

2225†

3838†

0R1

100

101

102

0.1pF

10pF

100pF

1000pF

A

B

C

D

F

G

J

K

±0.05pF

±0.1pF

±0.25pF

±0.5pF

±1%

±2%

±5%

±10%

50

100

1000

50V

100V

1000V

W

S

M

Ag/Cu/Sn

Pd/Ag

Poly/Cu/Sn

H

F

AH +90±20ppm/ºC

CF 0±15ppm/ºC

B = Chip

R =Ribbon

Note:

†Available in chip or ribbon leaded format.
