Ordering information - Voltronics Non-Magnetic capacitors

11

470

J

1000

W

F

R

Chip size

Capacitance

Tolerance

Voltage

Termination

Material

Lead/

Packaging

4

5

6

8

11

12

13

18

22

25

38

40

0402*

0505

0603*

0805*

1111†

1206*

1210*

1812*

2220*

2225†

3838†

4040†

0R1

100

101

102

0.1pF

10pF

100pF

1000pF

A

B

C

D

F

G

J

K

M

±0.05pF

±0.1pF

±0.25pF

±0.5pF

±1%

±2%

±5%

±10%

±20%

50 = 50V

100 = 100V

1000 =1000V

W = Ag/Cu/Sn

S = Pd/Ag

M = Poly/Cu/Sn

2 = Ag/Cu/Sn - (Q dielectric only)

3 = Poly/Cu/Sn - (X dielectric only)

B = Silver - (Q ribbon only)

V = Silver, laquer Coated - (Q ribbon only)

Q = High Q

0±30ppm/ºC

X = X7R (2R1)

R = Ribbon

T* = Tape & Reel

B* = Bulk

Note: *Q and X dielectric only. †Ribbon Leads available.

Ordering information - Syfer Non-Magnetic capacitors

1206

2

500

0223

J

Q

T

-

-

4040

2

7K0

0470

G

Q

B

-

AF9

2225

B

3K0

6P80

G

Q

B

R

W221

Chip

size

Termination or Coating

(Ribbon Leaded)

Voltage

Capacitance in picofarads

(pF)

Capacitance

tolerance

Dielectric

Packing

Lead

Options Suffix code

0402*

0603

0505

0805

1206

1111

1210

1808

1812

2220

2225†

4040†

2 = Sintered silver with

copper barrier*

3 = FlexiCap™ with

copper barrier.

4 = Sintered silver with

copper barrier*

5 = FlexiCap™ base with

copper barrier.

Ribbon Leaded

B = Uncoated

V = Coated with modified

silicone laquer

50 = 50V

100 = 100V

1K0 = 1kV

2K0 = 2kV

3K0 = 3kV

4K0 = 4kV

5K0 = 5kV

6K0 = 6kV

7K0 = 7kV

<10pF Insert a P for the

decimal point,

eg 2P20 = 2.2pF.

>10pF. 1st digit is 0.

2nd and 3rd digits are

significant figures of

capacitance code. The

4th digit is number of 0’s

following

eg. 0470 = 47pF

0512 = 5100pF

Values <1pF in 0.1pF steps,

above this values are E24 series

<4.7pF

H = ±0.05pF

B = ±0.1pF

C = ±0.25pF

D = ±0.5pF

4.7pF ~ <10pF

B = ±0.1pF

C = ±0.25pF

D = ±0.5pF

10pF

F = ±1%

G = ±2%

J = ±5%

K = ±10%

M = ±20%

C = C0G/

NP0 (1B)

Q = High Q

X = X7R

(2R1)

T = 178mm

(7”) reel

R = 330mm

(13”) reel

B = Bulk

pack - tubs

or trays

R =

Ribbon

leaded

Blank =

SM chip

W221 =

Leaded

W211 =

Leaded

marked

**AF9 =

SM standard

chip

**AF9LM =

SM marked

standard chip

Note: *0402 - C0G/NP0 (1B) and High Q only. †Ribbon Leads available. **AF9 and AF9LM suffix code only available in 1111, 2225 and 4040 chip sizes.

2225

4040

12.0 max

(0.473 max)

50 typ

(1.97 typ)

35 typ

(1.378 typ)

9.3 max

(0.366 max)

T

L2

W

Surface Mount See MLC Caps catalogue for dimensions.

Ribbon Leaded Silver plated copper ribbon attached with HMP solder - (MP greater than 260ºC).

a Knowles Precision Devices brand

TM

Non-Magnetic Caps - C0G/NP0 (1B), High Q, X7R (2R1)
