RT8800AGQV datasheet(6/21 Pages) RICHTEK

6 / 21 page

RT8800A

DS8800A-04 August 2007

www.richtek.com

All brand name or trademark belong to their owner respectively

Parameter

Symbol

Test Conditions

Min

Typ

Max

Units

Error Amplifier

DC Gain

Gain-Bandwidth Product

GBW

CL = 10pF

MHz

Slew Rate

CL = 10pF

μs

Current Sense GM Amplifier

Recommended Full Scale Source Current

100

μA

Protection

Over-Voltage Trip (VFB – VPI)

500

Power Good

PGOOD Output Low Voltage

VPGOOD

IPGOOD = 4mA

0.2

PGOOD Delay

TPGOOD_Delay 90% * VOUT to PGOOD_H

Note 1.

Stresses listed as the above "Absolute Maximum Ratings" may cause permanent damage to the device. These are for

stress ratings. Functional operation of the device at these or any other conditions beyond those indicated in the

operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended

periods may remain possibility to affect device reliability.

Note 2.

Devices are ESD sensitive. Handling precaution recommended.

Note 3.

The device is not guaranteed to function outside its operating conditions.

Note 4.

θJA is measured in the natural convection at TA = 25°C on a low effective thermal conductivity test board of

JEDEC 51-3 thermal measurement standard.
