background image
RT8800A
8
DS8800A-04 August 2007
www.richtek.com
All brand name or trademark belong to their owner respectively
Time (25
μs/Div)
VID On the Fly Falling
VFB
(200mV/Div)
VID0
(2V/Div)
PWM
(5V/Div)
VCORE
(100mV/Div)
IOUT = 5A
Time (2.5
μs/Div)
Load Transient Response
UGATE1
(20V/Div)
VCORE
(200mV/Div)
UGATE2
(20V/Div)
UGATE3
(20V/Div)
phase 1, IOUT = 5A to 85A @SR = 93A/us)
Time (2.5
μs/Div)
Load Transient Response
UGATE1
(20V/Div)
VCORE
(200mV/Div)
UGATE2
(20V/Div)
UGATE3
(20V/Div)
phase 3, IOUT = 5A to 85A @SR = 93A/us)
Time (10ms/Div)
Over Current Protection
IL1+IL2
(50A/Div)
VCORE
(1V/Div)
PWM1
(10V/Div)
VCOMP
(2V/Div)
Short While Turn_On
Time (10ms/Div)
Over Current Protection
IL1+IL2
(50A/Div)
VCOMP
(2V/Div)
PWM1
(10V/Div)
VCORE
(1V/Div)
Short After Turn_On
Time (2.5
μs/Div)
Load Transient Response
UGATE1
(20V/Div)
VCORE
(200mV/Div)
UGATE2
(20V/Div)
UGATE3
(20V/Div)
phase2, IOUT = 5A to 85A @SR = 93A/us)
