28 / 48 page ![]() STRAP OPTION 28/48 Issue 1.7 - February 8, 2000 Note; Setting of Strap Options MD [15:2] have no effect on the DRAM Controller but are purely meant for software issues. i.e. Readable in a reg- ister. 3.1 Power on strap registers description 3.1.1 Strap register 0 Index 4Ah (Strap0) Bits 7-0; This register reflect the status of pins MD[7:0] respectively. They are expected to be connected on the system board to the SIMM con- figuration pins as follows: Note that the SIMM speed and type information read here is meant only for the software and is not used by the hardware. The software must pro- gram the Host and graphics dram controller con- figuration registers appropriately based on these bits. This register defaults to the values sampled on MD[7:0] pins after reset. 3.1.2 Strap register 1 Index 4Bh (Strap1) Bits 7-0; This register reflect the status of pins MD[15:8] respectively. They are expected to be connected on the system board to the SIMM con- figuration pins as follows: Note that the SIMM speed and type information read here is meant only for the software and is not used by the hardware. The software must pro- gram the Host and graphics dram controller con- figuration registers appropriately based on these bits. This register defaults to the values sampled on MD[15:8] pins after reset. 3.1.3 Strap register 2 Index 4Ch (Strap2) Bits 4-0; This register reflect the status of pins MD[20:16] respectively.They are use by the chip as follows: Bit 4-2; Reserved. Bit 1; This bit reflects the value sampled on MD[17] pin and controls the PCI clock output as follows: 0: PCI clock output = HCLK / 2 1: PCI clock output = HCLK / 3. Bit 0; Reserved. This register defaults to the values sampled on MD[20:16] pins after reset. MD38 - Reserved - - - - MD39 - Reserved - - - - MD40 - Reserved - - - - MD41 - Reserved - - - - MD42 - Reserved - - - - MD43 - Reserved - - - - Memory Data Lines Refer to Designation Location Actual Settings Set to ’0’ Set to ’1’ Bit Sampled Description Bit 7 SIMM 0 DRAM type Bits 6-5 SIMM 0 speed Bit 4 SIMM 1 DRAM type: Bits 3-2 SIMM 1 speed Bit 1 Reserved Bit 0 Reserved Bit Sampled Description Bit 7 SIMM 2 DRAM type Bits 6-5 SIMM 2 speed Bit 4 SIMM 3 dram type Bits 3-2 SIMM 3 speed Bit 1 Reserved Bit 0 Reserved |
|
