CS2000-CP

DS761F1

5.3

Output to Input Frequency Ratio Configuration

5.3.1

User Defined Ratio (RUD), Frequency Synthesizer Mode

The User Defined Ratio, RUD, is a 32-bit un-signed fixed-point number which determines the basis for the

desired input to output clock ratio. Up to four different ratios, Ratio0-3, can be stored in the CS2000 register

space. The ratio pointed to by the RSel[1:0] bits is the currently selected ratio for the static ratio based

Frequency Synthesizer Mode. The 32-bit RUD is represented in a high-resolution 12.20 format where the

12 MSBs represent the integer binary portion while the remaining 20 LSBs represent the fractional binary

portion. The maximum multiplication factor is approximately 4096 with a resolution of 0.954 PPM in this

configuration. See “Calculating the User Defined Ratio” on page 34 for more information.

The status of internal dividers, such as the internal timing reference clock divider, are automatically taken

into account. Therefore RUD is simply the desired ratio of the output to input clock frequencies.

5.3.2

User Defined Ratio (RUD), Hybrid PLL Mode

The same four ratio locations, Ratio0-3, are used to store the User Defined Ratios for Hybrid PLL Mode.

The User Defined Ratio pointed to by the LockClk[1:0] bits is the currently selected ratio for the dynamic

ratio based Hybrid PLL Mode.

In addition to the High-Resolution format, a High-Multiplication format is also available. In the High-Multi-

plication Format Mode, the 32-bit RUD is represented in a 20.12 format where the 20 MSBs represent the

integer binary portion while the remaining 12 LSBs represent the fractional binary portion. In this config-

uration, the maximum multiplication factor is approximately 1,048,575 with a resolution of 244 PPM.

The ratio format default is 20.12. The 20.12 ratio format is only available when both the LFRatioCfg bit is

cleared (20.12) and the FracNSrc bit is set (dynamic ratio). In Auto Fractional-N Source Mode (see section

5.3.5.2 on page 21) when CLK_IN is not present the LFRatioCfg bit is ignored and the ratio format is

12.20.

It is recommended that the 12.20 High-Resolution format be utilized whenever the desired ratio is less

than 4096 since the output frequency accuracy of the PLL is directly proportional to the accuracy of the

timing reference clock and the resolution of the RUD.

Referenced Control

Ratio0-3.................................“Ratio 0 - 3 (Address 06h - 15h)” on page 31

Rsel[1:0] ................................ “Ratio Selection (RSel[1:0])” on page 29

Referenced Control

LockClk[1:0] .......................... “Lock Clock Ratio (LockClk[1:0])” section on page 30

LFRatioCfg ............................ “Low-Frequency Ratio Configuration (LFRatioCfg)” on page 32

FracNSrc ............................... “Fractional-N Source for Frequency Synthesizer (FracNSrc)” section on page 30
