11.ORDERING INFORMATION

12.REFERENCES

1.

Audio Engineering Society AES-12id-2006: “AES Information Document for digital audio measurements -

Jitter performance specifications,” May 2007.

2.

Philips Semiconductor, “The I²C-Bus Specification: Version 2,” Dec. 1998.

http://www.semiconductors.philips.com

13.REVISION HISTORY

Product

Description

Package

Pb-Free

Grade

Temp Range Container

Order#

CS2000-CP

Clocking Device

10L-MSOP

Yes

Commercial

-10° to +70°C

Rail

CS2000CP-CZZ

CS2000-CP

Clocking Device

10L-MSOP

Yes

-10° to +70°C

Tape and

Reel

CS2000CP-CZZR

CDK2000

Evaluation Platform

-

Yes

-

-

-

CDK2000-CLK

Release

Changes

F1

Updated Period Jitter specification in “AC Electrical Characteristics” on page 8.

Updated Crystal and Ref Clock Frequency specifications in “AC Electrical Characteristics” on page 8.

Added “PLL Performance Plots” section on page 9.

Updated “Internal Timing Reference Clock Divider” on page 14 and added Figure 11 on page 14.

Updated use conditions for “CLK_IN Skipping Mode” section on page 15 and page 31.

Updated Figure 13 on page 16.

Removed FsDetect and Auto R-Mod features per ER758rev2.

Contacting Cirrus Logic Support

For all product questions and inquiries, contact a Cirrus Logic Sales Representative.

To find one nearest you, go to www.cirrus.com
