CS2000-CP

DS761F1

21

5.3.5

Fractional-N Source Selection

To select between the static ratio based Frequency Synthesizer Mode and the dynamic ratio based Hybrid

PLL Mode, the source for the fractional-N value for the Frequency Synthesizer must be changed. The

Fractional-N value can either be sourced directly from the Effective Ratio (static ratio) or from the output

of the Digital PLL (dynamic ratio) (see Figure 18 on page 22). The setting of this function can be made

manual or automatically depending on the presence of CLK_IN.

5.3.5.1

Manual Fractional-N Source Selection for the Frequency Synthesizer

Manual selection of the fractional-N source for the frequency synthesizer is made by setting the

FracNSrc bit to select the desired ratio source. The LockClk[1:0] bits (even if unused) must be set

to the same value as the RSel[1:0] bits in order to maintain manual selectability of this function (see

Section 5.3.5.2 on page 21).

5.3.5.2

Automatic Fractional-N Source Selection for the Frequency Synthesizer

Automatic source selection allows for the selection of the frequency synthesizer’s fractional-N value

to be made dependent on the presence of the CLK_IN signal. When CLK_IN is present the device

will use the dynamic ratio generated from the Digital PLL and CLK_IN for Hybrid PLL Mode. When

CLK_IN is not present, the device will use RefClk and the static ratio for Frequency Synthesizer

after losing CLK_IN (see “CLK_IN Skipping Mode” on page 15).

The User Defined Ratio pointed to by RSel[1:0] should contain the desired CLK_OUT to RefClk ra-

tio to be used when CLK_IN is not present. The User Defined Ratio pointed to by LockClk[1:0]

should contain the desired CLK_OUT to CLK_IN ratio to be used when CLK_IN is present. Auto-

matic source selection is enabled when the LockClk[1:0] bits are set to point to a different User De-

fined Ratio from the one pointed to by the RSel[1:0] bits.

When automatic source selection is enabled, the FracNSrc bit (used for manual clock selection) will

be ignored.

To disable the automatic source selection feature, set the LockClk[1:0] bits and the RSel[1:0] bits

to the same value. The FracNSrc bit must then be used to select the desired clock used for the

PLL’s frequency reference.

Referenced Control

Register Location

Rsel[1:0]................................ “Device Configuration 1 (Address 03h)” on page 29

LockClk[1:0] .......................... “Device Configuration 2 (Address 04h)” section on page 30

FracNSrc............................... “Device Configuration 2 (Address 04h)” section on page 30

Referenced Control

Register Location

RSel[1:0] ............................... “Ratio Selection (RSel[1:0])” on page 29

LockClk[1:0] .......................... “Lock Clock Ratio (LockClk[1:0])” section on page 30

FracNSrc............................... “Fractional-N Source for Frequency Synthesizer (FracNSrc)” section on page 30
