23 / 89 page  Pushbuttons and Indicating Lights CA04716001E—March 2009 www.eaton.com 23 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47.4 Pushbuttons and Indicating Lights M22 Modular Pushbuttons Illuminated Pushbuttons, Extended, Maintained Components Button Lenses Buttonless Operator Light Units Contact Blocks Notes Maintained pushbuttons can be converted in the field to momentary operation by switching the locking ring, which is accessible through the side of the operator body. For complete listing of available button lenses, light units and contact blocks, see Accessories, Pages 59–64. Minimum order quantity of (10). When ordering, specify inscription per catalog number suffix from the symbols library (see Pages 77–84) into the Order Notes. For example, M22-XDLH-S-ETCH; Order Notes: Mark with symbol X91, Line item #_. Discount Symbol: 1CD1. max. 5mm thick ness Note: Included with operator. Color Inscription Catalog Number Price U.S. $ Red — M22-XDLH-R 2.40 Custom M22-XDLH-R-ETCH 3.40 STOP M22-XDLH-R-GB0 3.40 OFF M22-XDLH-R-GB5 3.40 M22-XDLH-R-X0 3.40 Green — M22-XDLH-G 2.40 Custom M22-XDLH-G-ETCH 3.40 START M22-XDLH-G-GB1 3.40 ON M22-XDLH-G-GB6 3.40 M22-XDLH-G-X1 3.40 Blue — M22-XDLH-B 2.40 Custom M22-XDLH-B-ETCH 3.40 RESET M22-XDLH-B-GB14 3.40 M22-XDLH-B-X6 3.40 White — M22-XDLH-W 2.40 Custom M22-XDLH-W-ETCH 3.40 Yellow — M22-XDLH-Y 2.40 Custom M22-XDLH-Y-ETCH 3.40 Bezel Catalog Number Price U.S. $ Silver M22-DRL-X 14.10 Black M22S-DRL-X 12.60 M22-XDLH-W M22-DRL-X M22S-DRL-X Terminal Type LED Color Light Unit Voltage Catalog Number Price U.S. $ White 12–30 Vac/dc M22-LED-W 26.00 Red M22-LED-R 26.00 Green M22-LED-G 26.00 Blue M22-LED-B 26.00 White 85–264 Vac M22-LED230-W 26.00 Red M22-LED230-R 26.00 Green M22-LED230-G 26.00 Blue M22-LED230-B 26.00 Terminal Type Contact Configuration Catalog Number Price U.S. $ Screw NO M22-K10 10.00 NO, Early-Make M22-K10P 11.00 NC M22-K01 10.00 NC, Late-Break M22-K01D 11.00 Spring-Cage NO M22-CK10 13.00 NC M22-CK01 13.00 NC, Late-Break M22-CK01D 11.00 2NO M22-CK20 23.00 2NC M22-CK02 23.00 NO-NC M22-CK11 23.00 M22-LED-W M22-K10 |
|
