M22-DP-R 数据表(PDF) 47 Page - List of Unclassifed Manufacturers |
|
|
|||||||||||||||||||||||||||||
M22-DP-R 数据表(HTML) 47 Page - List of Unclassifed Manufacturers |
|
|
47 / 89 page  Pushbuttons and Indicating Lights CA04716001E—March 2009 www.eaton.com 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47.4 Pushbuttons and Indicating Lights M22 Modular Pushbuttons Non-Illuminated Mushroom Head Pushbuttons, Maintained Components Mushroom Head Plates Insertless Mushroom Head Operators Contact Blocks Notes 35 mm diameter mushroom head button. Maintained pushbuttons can be converted in the field to momentary operation by switching the locking ring, which is accessible through the side of the operator body. Minimum order quantity of (10). When ordering, specify inscription per catalog number suffix from the symbols library (see Pages 77–84) into the Order Notes. For example, M22-XDP-S-ETCH; Order Notes: Mark with symbol X91, Line item #_. For complete listing of available button plates and contact blocks, see Accessories, Pages 59–64. Discount Symbol: 1CD1. Note: Included with operator. Color Inscription Catalog Number Price U.S. $ Black — M22-XDP-S 1.00 Custom M22-XDP-S-ETCH 2.00 STOP M22-XDP-S-GB0 2.00 START M22-XDP-S-GB1 2.00 FORWARD M22-XDP-S-GB15 2.00 REVERSE M22-XDP-S-GB16 2.00 UP M22-XDP-S-GB3 2.00 DOWN M22-XDP-S-GB4 2.00 OFF M22-XDP-S-GB5 2.00 ON M22-XDP-S-GB6 2.00 M22-XDP-S-X0 2.00 M22-XDP-S-X1 2.00 M22-XDP-S-X4 2.00 M22-XDP-S-X5 2.00 M22-XDP-S-X7 2.00 Red — M22-XDP-R 1.00 Custom M22-XDP-R-ETCH 2.00 STOP M22-XDP-R-GB0 2.00 OFF M22-XDP-R-GB5 2.00 M22-XDP-R-X0 2.00 Green — M22-XDP-G 1.00 Custom M22-XDP-G-ETCH 2.00 START M22-XDP-G-GB1 2.00 ON M22-XDP-G-GB6 2.00 M22-XDP-G-X0 2.00 M22-XDP-G-X1 2.00 White — M22-XDP-W 1.00 Custom M22-XDP-W-ETCH 2.00 Yellow — M22-XDP-Y 1.00 Custom M22-XDP-Y-ETCH 2.00 M22-XDP-G Bezel Color Catalog Number Price U.S. $ Silver Black M22-DRP-S-X 38.50 Red M22-DRP-R-X 38.50 Green M22-DRP-G-X 38.50 Yellow M22-DRP-Y-X 38.50 Black Black M22S-DRP-S-X 37.00 Red M22S-DRP-R-X 37.00 Green M22S-DRP-G-X 37.00 Yellow M22S-DRP-Y-X 37.00 Terminal Type Contact Configuration Catalog Number Price U.S. $ Screw NO M22-K10 10.00 NO, Early-Make M22-K10P 11.00 NC M22-K01 10.00 NC, Late-Break M22-K01D 11.00 Spring-Cage NO M22-CK10 13.00 NC M22-CK01 13.00 NC, Late-Break M22-CK01D 11.00 2NO M22-CK20 23.00 2NC M22-CK02 23.00 NO-NC M22-CK11 23.00 M22-DRP-G-X M22-K10 |
|
