Pushbuttons and Indicating Lights CA04716001E—March 2009

www.eaton.com

47.4

Pushbuttons and Indicating Lights

M22 Modular Pushbuttons

Legend Plates, Complete

Notes

When ordering, specify inscription per catalog number sufﬁx from the symbols library (see Pages 77–84) into the Order Notes. For example, M22-XD-S-ETCH;

Order Notes: Mark with symbol X91, Line item #_.

Discount Symbol: 1CD1.

Description

Inscription

Catalog Number

Price U.S. $

For use with Pushbuttons

and Indicating Lights

Legend plate holder with insert

STOP

M22S-ST-GB0

3.80

START

M22S-ST-GB1

3.80

OFF

M22S-ST-GB5

3.80

M22S-ST-GB6

3.80

RUN

M22S-ST-GB7

3.80

FAULT

M22S-ST-GB8

3.80

M22S-ST-X52

3.80

M22S-ST-X53

3.80

Selector Switches

—

OFF ON

M22S-ST-GB10

3.80

MAN. AUTO

M22S-ST-GB11

3.80

HAND O AUTO

M22S-ST-GB12

3.80

HAND AUTO

M22S-ST-D11

3.80

MAN. O AUTO

M22S-ST-D12

3.80

O I

M22S-ST-X88

3.80

O - I

M22S-ST-X89

3.80

I O II

M22S-ST-X93

3.80

Emergency-Stop Operators

Rectangular Yellow Legend Plate

—

M22-XZK

5.25

Custom

M22-XZK-ETCH

6.25

EMERGENCY-STOP

M22-XZK-GB99

6.25

Square Yellow Legend Plate

Custom

M22-XYK

5.25

Custom

M22-XYK-ETCH

6.25

EMERGENCY-STOP 4-Language

M22-XYK1

6.25

EMERGENCY-STOP (top and bottom) M22-XYK5

6.25

Round Yellow Legend Plate, 90 mm

—

M22-XAK

5.25

Custom

M22-XAK-ETCH

6.25

EMERGENCY-STOP 4-Language

M22-XAK1

6.25

EMERGENCY-STOP (top and bottom) M22-XAK5

6.25

Round Yellow Legend Plate, 60 mm

—

M22-XBK

5.25

Custom

M22-XBK-ETCH

6.25

EMERGENCY-STOP 4-Language

M22-XBK1

6.25

EMERGENCY-STOP (top and bottom) M22-XBK5

6.25

Four-Way Pushbutton,

Joystick and 4-Position

Selector Switches

Silver Square Legend Plate

—

M22-XCK

7.75

Custom

M22-XCK-ETCH

8.75

4 Directional Arrows

M22-XCK1

8.75

0-1-0-2-0-3-0-4

M22-XCK2

8.75

2 Directional Arrows

M22-XCK3

8.75

M22S-ST-GB0

M22-XZK

M22-XBK1

M22-XCK1

M22-XYK
