Data Sheet

ADPA7009-2

BIASING THE ADPA7009-2 WITH THE HMC980LP4E

analog.com

Rev. 0 | 23 of 24

Figure 74. PSAT vs. Frequency for Various Temperatures, VDD = 5 V, Data

Measured with Constant IDD = 950 mA

Figure 75. PSAT vs. Frequency for Various IDQ Values, VDD = 5 V, Data

Measured with Constant IDD

Figure 76. PAE vs. PIN, VDD = 5 V, Frequency = 36 GHz, Constant Drain

Current (IDRAIN Setpoint = 950 mA) and Constant Gate Voltage (IDQ = 850 mA)

Figure 77. POUT vs. PIN, VDD = 5 V, Frequency = 36 GHz, Constant Drain

Current (IDRAIN Setpoint = 950 mA) and Constant Gate Voltage (IDQ = 850 mA)

Figure 78. OP1dB vs. Frequency, VDD = 5 V, Constant Drain Current (IDRAIN

Setpoint = 950 mA) and Constant Gate Voltage (IDQ = 850 mA)
