Features

•

Operating voltage from 6 to 50 V

•

Gate drivers with programmable current capability up to:

–

1 A source current

–

2 A sink current

•

High robustness against below-ground and overshoot

•

Charge pump for 100 % duty cycle operation with dedicated undervoltage

lockout protection

•

Flexible power management:

–

12 V LDO linear regulator with dedicated undervoltage lockout

protection

–

3.3 V LDO linear regulator with dedicated undervoltage lockout

protection

•

Standby mode for low consumption less than 50 nA

•

Thermal shutdown protection

•

VDS monitoring for safe driving operation of the power MOSFETs

•

Flexible analog front-end:

–

Up to three wide-bandwidth operational amplifiers

–

Up to three high-speed comparators

•

Dual control modes:

–

ENx/INx

–

INHx/INLX with interlocking

•

Matched propagation delay for all channels

•

Logic inputs up to 5 V, TTL compatible

Applications

•

Battery supplied power tools

•

Portable vacuum cleaners

•

E-bikes

•

Industrial automation

•

Robotics

•

Pumps and fans

Description

The STDRIVE102BH and the STDRIVE102H are triple half-bridge gate drivers

suitable for 3-phase brushless motor driving.

The STDRIVE102BH/H is the optimal solution for battery supplied motor driver

applications such as power tools, vacuum cleaner and small appliances thanks to its

very efficient stand-by mode, that strongly reduce the current consumption when the

device is not active.

VFQFPN 48L, 6x6x1 mm

VFQFPN 40L, 5x5x1 mm

Product status link

STDRIVE102BH

STDRIVE102H

Product label

Triple half-bridge gate driver with programmable currents

STDRIVE102BH, STDRIVE102H

Datasheet

DS14545 - Rev 1 - March 2025
