Transmitter Encoder RF600E

Operational Description

The RF600E is a simple device to use. As shown in the typical application circuits, it requires only the

addition of input switches and RF circuitry for use as the transmitter in the end application. Transmission is

automatic without user intervention.

The RF600E will wake up upon detecting a switch closure and then delay approximately 6.5 ms for switch

debounce. The encrypted or hopping code portion of the transmission will change every time a button is

pressed, even if the same button is pushed again.

Achieving Optimum Range

Range is dependant on many factors including

1.

RF Power output

2.

Receiver sensitivity

3.

Antenna efficiency

4.

Local environmental conditions and any local Interference

5.

Data Type which is being transmitted.

Whilst items 1-4 are dependant on the system hardware design, item ‘5’ is equally important and often

overlooked.

Given that there is a legal maximum power output which can be transmitted, and a limit on the sensitivity

of the receiver (usually constrained by cost), and that the antenna can never achieve 0dB loss (100%

efficiency), then the data type is an important aspect of the design.

The RF600E/D chipset use a fully balanced Manchester encoded data protocol designed for optimum use

of the radio transmission path.

The data format automatically includes a pre-amble, synchronisation header, followed by the encrypted

and fixed code data then a CRC check. The actual packet size is 67 bits. Each transmission is followed by

a guard period before another transmission can begin.

The data encryption provides up to four billion changing code combinations and includes the function bits

(based on which buttons were activated) along with other data and synchronization information that the

decoder uses.

Manchester encoding the data enables the superhetrodyne receiver ‘data slicer’ to maintain efficiency for

the duration of the data packet, (unlike many other encoder/decoder systems) which results in reduced bit

errors and therefore ensures maximum range.

Low Battery Indication

The RF600E reads the battery status (voltage) on each operation. If the voltage is detected as being

below 3.8 volts (typical) then a flag bit is transmitted to the decoder where it is made available.

Custom Versions

Custom versions of the RF600E / D chipset are available, programmed with a unique ‘Manufacturers Key’

which means that the transmitter and receiver will respond only to other devices with the same unique

manufacturers key. This provides a bespoke remote chipset for OEM applications. Please contact our

sales department for further information.
