RF / IR Encoder / Decoder Chipset

RF600E

RF Evaluation Boards,

RF600D

Ordering Information

Part Number

Description

Package

RF600E

Encoder IC

8pin PDIP

RF600E-SO

Encoder IC

8pin SO-8

RF600DR6

Decoder IC

18pin PDIP

RF600DR6-SO

Decoder IC

18pin SO-8

RF600D8R6

Decoder IC Serial output only

8pin PDIP

RF600D-SO8R6

Decoder IC Serial Output only

8pin SO-8

RF600DP8 / RF600DS8

The Decoder is available as a miniature 8 pin version option providing a serial data output only. These

devices are designed for small space applications requiring a low cost solution.

SD

NC

IN

RF600D8

RF600D 8 Pin version

8

7

6

5

MD

NC

2

3

4

1

NC

Pin Descriptions

Pin

Number

Name

Input /

Output?

Description

1

Vcc

In

Positive supply voltage connection

2

SD

Out

Serial Data output

3

NC

-

No connection

4

IN

In

RF / IR Data input

5

NC

-

No connection

6

MS

Input

Mark Select

For FM / IR connect to Vcc

For AM connect to Gnd

7

NC

-

No connection

8

Vss

In

Connect to GND

DS600-9 Sept ‘04

©2004 Reg. No. 227 4001, ENGLAND

Page 12
