Timer Interval Indicator

K3HB-P

13

Operation

■ Functions (Operating Modes)

F1 to F6

These functions use the internal system clock to measure the time between pulses or the pulse ON time and then display time measurements or

a variety of other calculations.

Function name

Function No.

Passing speed

f1

Cycle

f2

Time difference

f3

Time band

f4

Measuring length

f5

Interval

f6

The time (T) between input A pulse and input B pulse

is measured by the internal system clock. If, for

example, the system clock measures 100,000 counts

during time T, then

T = 1 system clock count (0.5

µs) × 100,000

T = 0.05 s

F1 (the passing speed) is calculated internally

using the formula

× 60 (m/min), and the

display, in this example, would be

× 60=

1200 (m/min).

1

T

1

0.05 s

Input A

Input B

Internal

system clock

1

1

T

Example: F1 Passing Speed

Function

Operation

Operation image (application)

F1

Passing

speed

The reciprocal of the time (T) from input A ON to input

B ON is multiplied by 60 and displayed.

starting the next measurement.

Display unit:

mm/s, m/s

m/min, km/h, etc.

Measuring workpiece passing speed between A and B

F2

Cycle

Measures and displays input A cycle (T).

Display unit:

ms, s, min.,

min.s.1/10 s

Measuring feed cycles for parts

F3

Time dif-

ference

Displays the time (T) from input A ON to input B ON.

• Recovery time (TR) of 20 ms is required before

starting the next measurement.

Display unit:

ms, s, min.,

min.s.1/10 s

Input A

Input B

Display

HOLD input

1 × 60

1 × 60

1 × 60

æ

ç

ç

è

ö

÷

÷

ø

A

B

Input A

Display

HOLD input

Measurement range: 20 ms to 3,200 s

æ

ç

ç

è

ö

÷

÷

ø

Input A

Input B

Display

HOLD input

Measurement range: 10 ms to 3,200 s

æ

ç

ç

è

ö

÷

÷

ø

A

B

Measuring workpiece passing time

between A and B

Measuring the length of a

workpiece step by changing

prescale values.
