Data Sheet

ADA4661-2

Rev. 0 | Page 21 of 32

Figure 66. THD + N vs. Amplitude

Figure 67. Channel Separation vs. Frequency

Figure 68. THD + N vs. Amplitude

Figure 69. Channel Separation vs. Frequency

0.001

0.01

0.1

100

0.001

0.01

0.1

AMPLITUDE (V rms)

80kHz LOW-PASS FILTER

500kHz LOW-PASS FILTER

VSY = 3V

AV = 1

RL = 10kΩ

f = 1kHz

–160

–140

–120

–100

–80

–60

–40

–20

100

10k

100k

FREQUENCY (Hz)

VIN = 0.5V p-p

VIN = 1.5V p-p

VIN = 2.9V p-p

VSY = 3V

AV = 100

RL = 10kΩ

500kHz LOW-PASS FILTER

0.0001

0.001

0.01

0.1

100

0.001

0.01

0.1

AMPLITUDE (V rms)

VSY = 18V

AV = 1

RL = 10kΩ

f = 1kHz

80kHz LOW-PASS FILTER

500kHz LOW-PASS FILTER

100

10k

100k

FREQUENCY (Hz)

–160

–140

–120

–100

–80

–60

–40

–20

VIN = 0.5V p-p

VIN = 9V p-p

VIN = 17.9V p-p

VSY = 18V

AV = 100

RL = 10kΩ

500kHz LOW-PASS FILTER
