ISL8117

FN8666.3

June 4, 2015

Submit Document Feedback

Absolute Maximum Ratings

Thermal Information

VCC5V to GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to +5.9V

EXTBIAS to GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to +5.9V

VIN to GND. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to +62.5V

BOOT/UGATE to PHASE . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to VCC5V+0.3V

PHASE and ISEN to GND . . . . . . . . . . . . . -5V (<20ns)/-0.3V (DC) to +62.5V

EN, PGOOD, SS/TRK, FB to GND. . . . . . . . . . . . . . . . . -0.3V to VCC5V+0.3V

LGATE/OCS to GND . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3V to VCC5V+0.3V

RT, MOD/SYNC, CLKOUT to GND. . . . . . . . . . . . . . . . . -0.3V to VCC5V+0.3V

VCC5V Short-circuit to GND Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1s

ESD Rating

Human Body Model (Tested per JS-001-2010) . . . . . . . . . . . . . . . . . . 4kV

Machine Model (Tested per JESD22-A115C) . . . . . . . . . . . . . . . . . . 400V

Charge Device Model (Tested per JESD22-C101E). . . . . . . . . . . . . . . 2kV

Latch-up (Tested per JESD78D; Class II, Level A, +125°C) . . . . . . . 100mA

Thermal Resistance (Typical)

JA (°C/W) JC (°C/W)

16 Ld QFN Package (Notes 4, 5) . . . . . . . .

2.5

16 Ld HTSSOP Package (Notes 4, 5) . . . . .

4.5

Maximum Junction Temperature . . . . . . . . . . . . . . . . . . . .-55°C to +150°C

Maximum Operating Temperature . . . . . . . . . . . . . . . . . . .-40°C to +125°C

Maximum Storage Temperature. . . . . . . . . . . . . . . . . . . . .-65°C to +150°C

Pb-free Reflow Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . see TB493

Recommended Operating Conditions

Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C to +125°C

VIN to GND. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.5V to 60V

VCC5V to GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-0.1V to 5.5V

EXTBIAS to GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.1V to +5.5V

CAUTION: Do not operate at or near the maximum ratings listed for extended periods of time. Exposure to such conditions may adversely impact product

reliability and result in failures not covered by warranty.

NOTES:

JA is measured in free air with the component mounted on a high effective thermal conductivity test board with “direct attach” features. See Tech

Brief TB379.

5. For

JC, the “case temp” location is the center of the exposed metal pad on the package underside.

Electrical Specifications Recommended operating conditions unless otherwise noted. Refer to “Block Diagram” on page 5 and “Typical

Application Schematics” on page 6. VIN = 4.5V to 60V, or VCC5V = 5V ±10%, C_VCC5V = 4.7µF, TA = -40°C to +125°C, Typical values are at TA = +25°C,

unless otherwise specified. Boldface limits apply across the operating temperature range, -40°C to +125°C.

SYMBOL

PARAMETER

TEST CONDITIONS

MIN

(Note 9)TYP

MAX

(Note 9)UNIT

VIN SUPPLY

VIN

Input Voltage Range

4.5

60.0

VIN SUPPLY CURRENT

IVINQ

Shutdown Current (Note 6)EN = 0

PGOOD is floating

µA

IVINOP

Operating Current (Note 8)

PGOOD is floating

2.5

VCC5V SUPPLY (Note 6)

VCC

Operation Voltage

VIN = 12V, IL = 0mA

4.85

5.1

5.4

Internal LDO Output Voltage

VIN = 4.5V, IL = 30mA

4.1

4.4

Internal LDO Output Voltage

VIN > 5.6V, IL = 75mA

4.75

5.05

IVCC_MAX

Maximum Supply Current of Internal LDO

VVCC5V = 0V, VIN = 12V

120

EXTBIAS SUPPLY (Note 6)

VEXT_THR

Switch Over Threshold Voltage, Rising

EXTBIAS voltage

4.5

4.7

4.9

VEXT_THF

Switch Over Threshold Voltage, Falling

EXTBIAS voltage

4.2

4.5

4.65

REXT

Internal Switch ON-resistance

VIN = 12V

1.5

UNDERVOLTAGE LOCKOUT

VUVLOTHR

Undervoltage Lockout, Rising

VIN voltage, 0mA on VCC5V

3.7

3.90

4.2

VUVLOTHF

Undervoltage Lockout, Falling

VIN voltage, 0mA on VCC5V

3.35

3.50

3.85

EN THRESHOLD

VENSS_THR

EN Rise Threshold

VIN > 5.6V

1.25

1.60

1.95

VENSS_THF

EN Fall Threshold

VIN > 5.6V

1.05

1.25

1.55

VENSS_HYST EN Hysteresis

VIN > 5.6V

180

350

500

SOFT-START CURRENT

ISS

SS/TRK Soft-start Charge Current

SS/TRK = 0V

2.00

µA
