USB Protocol Engine. The USB Protocol Engine manages the data stream from the device USB control

endpoint. It handles the low level USB protocol requests generated by the USB host controller. The

Protocol Engine also includes a memory management unit which handles endpoint buffers.

OUT Buffer. Data sent from the USB host controller to FT120 via the USB data OUT endpoint is stored in

the OUT buffer. Data is removed from the OUT buffer to system memory under control of the parallel

interface block.

IN Buffer. Data from system memory is stored in the IN buffer. The USB host controller removes data

from the IN buffer by sending a USB request for data from the device data IN endpoint.

RESET Generator. The integrated Reset Generator cell provides a reliable power-on reset to the device

internal circuitry at power up. The RESET_n input pin allows an external device to reset the FT120.

Parallel Interface Block. The 8-bit parallel bus allows direct interface to a generic microcontroller

(MCU), supporting both multiplexed and non-multiplexed address/data bus configurations. The FT120

also supports Direct Memory Access (DMA) operation. With DMA access data can be written to the IN

buffer or read from the OUT buffer without MCU intervention. The DMA access can be done in single cycle

or burst mode.

The FT120 interrupt pin (INT_n) can be programmed to generate an interrupt in different modes. The

interrupt source can be any bit in the Interrupt Register, an SOF packet being received, or both. The

interrupt modes are selectable by two register bits, one is the SOF-only Interrupt Mode bit (bit 7 of Clock

Division Factor register), and the other is the Interrupt Pin Mode bit (bit 5 of DMA Configuration register).

Interrupt

mode

Bit SOF-only

Interrupt

Mode

Bit Interrupt

Pin Mode

Interrupt source

0

0

0

Any bit in Interrupt register

1

0

1

Any bit in Interrupt register and SOF

2

1

X

SOF only

Table 4-1 Interrupt modes
