Document No.: FT_000646

FT120 USB DEVICE CONTROLLER WITH PARALLEL BUS IC

Datasheet Version 1.2

Clearance No.: FTDI#

291

6.3.2 Select Endpoint

Command

: 00-05h (0ih where ‘i’ is the endpoint index (EPI) as defined in Table 5-1 and

Table 5-2)

Data

: Optional Read 1 byte

Bit

Symbol

Reset

Description

Full/Empty

0: selected endpoint buffer is empty

1: selected endpoint buffer is not empty

Stall

0: selected endpoint is not stalled

1: selected endpoint is stalled

7-2

Reserved

0b’xxxxxx

Reserved

Table 6-9 Endpoint Status Register

6.3.3 Read Last Transaction Status

Command

: 40-45h (4ih where ‘i’ is the endpoint index (EPI) as defined in Table 5-1 and

Table 5-2)

Data

: Read 1 byte

Bit

Symbol

Reset

Description

Data Receive/Transmit

Success

0: indicate USB data receive or transmit not OK

1: indicate USB data receive or transmit OK

4-1

Error Code

0b’0000

Refer to Table 6-11

Setup Packet

0: indicate not a setup packet

1: indicate last received packet has a SETUP token

Data 0/1 Packet

0: packet has a DATA0 token

1: packet has a DATA1 token

Previous Status not

Read

0: previous transaction status was read

0: previous transaction status was not read

Table 6-10 Endpoint Last Transaction Status Register

Error Code

Result

0000

No error

0001

PID encoding error

0010

PID unknown
