11 / 40 page ![]() Copyright © 2014 Future Technology Devices International Limited 11 Document No.: FT_000646 FT120 USB DEVICE CONTROLLER WITH PARALLEL BUS IC Datasheet Version 1.2 Clearance No.: FTDI# 291 5 Endpoint Buffer Management The FT120 has 3 physical endpoints (EP0, EP1 and EP2) or 6 logical endpoints (EPI0-EPI5). EP0 is the control endpoint, with 16 bytes maximum packet size for both control OUT (EPI0) and control IN (EPI1) endpoint. EP1 can be used as either a bulk endpoint or an interrupt endpoint, with 16 bytes maximum packet size for both OUT (EPI2) and IN (EPI3) endpoints. Table 5-1 shows the endpoint type and maximum packet size for EP0 and EP1. Endpoint Number Endpoint Index (EPI) Endpoint Direction Transfer Type Max Packet Size 0 0 1 OUT IN Control Control 16 16 1 2 3 OUT IN Bulk/Interrupt Bulk/Interrupt 16 16 Table 5-1 Endpoint configuration for EP0 and EP1 EP2 is the primary endpoint. It can be configured as either a bulk/interrupt or isochronous endpoint. The maximum packet size allowed for EP2 depends on the mode of configuration through the Set Mode command. Table 5-2 shows all the 4 endpoint configuration modes for EP2. Endpoint Configuration Mode (EP2) Endpoint Index (EPI) Endpoint Direction Transfer Type Max Packet Size 0 (default) 4 5 OUT IN Bulk/Interrupt Bulk/Interrupt 64 64 1 4 OUT Isochronous 128 2 5 IN Isochronous 128 3 4 5 OUT IN Isochronous Isochronous 64 64 Table 5-2 Endpoint configuration for EP2 As the primary endpoint, EP2 is suitable for transmitting or receiving relatively large data. To improve the data throughput, a pair of buffers (the ‘ping-pong’ buffer) is implemented for EP2 buffering. This allows the concurrent operation between USB bus access and MCU or DMA local bus access. For example, for EP2 IN endpoint (EPI5), the USB host can read data from FT120 ping buffer while the local MCU is writing to the pong buffer at the same time. The USB host can subsequently read from FT120 pong buffer without waiting for it to be filled. Buffer switching is handled automatically by FT120. |
|
