FT221X USB 8-BIT SPI/FT1248 IC Datasheet

Version 1.3

Document No.: FT_000630 Clearance No.: FTDI# 263

input receiver and two single ended input receivers provide USB data in, Single-Ended-0 (SE0) and USB

reset detection conditions respectfully. This function also incorporates a 1.5kΩ pull up resistor on USBDP.

The block also detects when connected to a USB power supply which will not enumerate the device but

still supply power and may be used for battery charging.

USB DPLL. The USB DPLL cell locks on to the incoming NRZI USB data and generates recovered clock

and data signals for the Serial Interface Engine (SIE) block.

Internal 12MHz Oscillator - The Internal 12MHz Oscillator cell generates a 12MHz reference clock. This

provides an input to the x4 Clock Multiplier function. The 12MHz Oscillator is also used as the reference

clock for the SIE, USB Protocol Engine and UART FIFO controller blocks.

Clock Multiplier / Divider. The Clock Multiplier / Divider takes the 12MHz input from the Internal

Oscillator function and generates the 48MHz, 24MHz, 12MHz and 6MHz reference clock signals. The 48Mz

clock reference is used by the USB DPLL and the Baud Rate Generator blocks.

Serial Interface Engine (SIE). The Serial Interface Engine (SIE) block performs the parallel to serial

and serial to parallel conversion of the USB data. In accordance with the USB 2.0 specification, it

performs bit stuffing/un-stuffing and CRC5/CRC16 generation. It also checks the CRC on the USB data

stream.

USB Protocol Engine. The USB Protocol Engine manages the data stream from the device USB control

endpoint. It handles the low level USB protocol requests generated by the USB host controller and the

commands for controlling the functional parameters of the UART in accordance with the USB 2.0

specification chapter 9.

FIFO RX Buffer (512 bytes). Data sent from the USB host controller to the FT1248 interface via the

USB data OUT endpoint is stored in the FIFO RX (receive) buffer. Data is removed from the buffer to the

FT1248 transmit register under control of the FT1248 FIFO controller. (Rx relative to the USB interface).

FIFO TX Buffer (512 bytes). Data from the FT1248 receive register is stored in the TX buffer. The USB

host controller removes data from the FIFO TX Buffer by sending a USB request for data from the device

data IN endpoint. (Tx relative to the USB interface).

FT1248 interface controller. Controls the FT1248 interface, dynamically switching the width of the bus

as commanded by the external bus master.

RESET Generator - The integrated Reset Generator Cell provides a reliable power-on reset to the device

internal circuitry at power up. The RESET# input pin allows an external device to reset the FT221X.

RESET# can be tied to VCC or left unconnected if not being used.
