1 / 67 page  Copyright © 2013 Future Technology Devices International Limited 1 Document No.: FT_000589 FT313H USB2.0 HS Host Controller Datasheet Version 1.2 Clearance No.: FTDI# 318 Future Technology Devices International Ltd. FT313H (USB2.0 HS Embedded Host Controller) The FT313H is a Hi-Speed Universal Serial Bus (USB) Host Controller compatible with Universal Serial Bus Specification Rev 2.0 and supports data transfer speeds of up to 480M bit/s. The FT313H has the following advanced features: Single chip USB2.0 Hi-Speed compatible. Compatible to Enhanced Host Controller Interface Specification Rev 1.0. The USB1.1 host is integrated into the USB2.0 EHCI compatible host controller. Single USB host port. Supports data transfer at high-speed (480M bit/s), full-speed (12M bit/s), and low-speed (1.5M bit/s). Supports the Isochronous, Interrupt, Control, and Bulk transfers. Supports the split transaction for high-speed Hub and the preamble transaction for full- speed Hub. Supports multiple processor interfaces with 8- bit or 16-bit bus: SRAM, NOR Flash, and General multiplex. Single configurable interrupt (INT) line for host controller. Integrated 24kB high speed RAM memory. Supports DMA operation. Integrated Phase-Locked Loop (PLL) supports external 12MHz, 19.2MHz, and 24MHz crystal, and direct external clock source input. Low power consumption for portable application. Supports bus interface I/O voltage from 1.62V to 3.63V. Supports hybrid power mode; VCC(3V3) is not present, VCC(I/O) is powered. Internal voltage regulator supplies 1.2v to the digital core. Supports Battery Charging Specification Rev 1.2. The downstream port can be configured as SDP, CDP or DCP. Supports VBUS power switching and over current control. -40°C to 85°C extended operating temperature range. Available in compact Pb-free 64 Pin QFN, LQFP and TQFP packages (all RoHS compliant). Neither the whole nor any part of the information contained in, or the product described in this manual, may be adapted or reproduced in any material or electronic form without the prior written consent of the copyright holder. This product and its documentation are supplied on an as-is basis and no warranty as to their suitability for any particular purpose is either made or implied. Future Technology Devices International Ltd will not accept any claim for damages howsoever arising as a result of use or failure of this product. Your statutory rights are not affected. This product or any variant of it is not intended for use in any medical appliance, device or system in which the failure of the product might reasonably be expected to result in personal injury. This document provides preliminary information that may be subject to change without notice. No freedom to use patents or other intellectual property rights is implied by the publication of this document. Future Technology Devices International Ltd, Unit 1, 2 Seaward Place, Centurion Business Park, Glasgow G41 1HH United Kingdom. Scotland Registered Company Number: SC136640 |
