4. DEVICE SPECIFICATION
4.1 ABSOLUTE MAXIMUM RATINGS
The absolute maximum ratings define values beyond which damage to the device may occur.
Inova Semiconductors may not be held liable for any product degradation or damage caused by a violation
of the absolute maximum ratings. Exposure to absolute maximum rating conditions for extended periods
may affect device reliability. Functional operation of the device at these or any other conditions above
those indicated in the recommended operating conditions is not guaranteed.
Parameter
Symbol
Min.
Max.
Units
Note
DC Supply Voltage
VCC
-0.5
+4.2
V
See handling
precautions (6)
Input Voltage
VIN
-0.5
VCC+0.5
V
I/O Current (DC or transient any pin)
ID
-20
+20
mA
See handling
precautions (6)
Junction Temperature (under bias)
Tj
-45
+140
° C
Storage Temperature
Tstg
-55
+150
° C
Soldering Temp./Time
TSLD / tSLD
220 / 10
° C / sec
Static Discharge Voltage (CMOS dig. I/O
versus respective GND & Supply rails)
VSDCMOS
± 2000
V
Human Body Model
Static Discharge Voltage (all other pin
combinations including CML I/O pins )
VSDCML
± 800
V
Human Body Model
Table 8: Absolute Maximum Ratings
4.2 RECOMMENDED OPERATING CONDITIONS
Parameter
Symbol
Min.
Max.
Units
Note
DC Supply Voltage
VCC
+3.15
+3.45
V
Input Voltage
VIN
0
Vcc
V
VCC =3.3V
± 0.15V
CML Output Current
IOUTCML
-10
+10
mA
CMOS Output Current
IOUTCMOS
-10
+10
mA
Junction Temperature (under bias)
Tj
-40
+125
° C
Ambient Temperature
Ta
-40
+85
° C
Table 9: Recommended Operating Conditions
4.3 ELECTRICAL SPECIFICATION
4.3.1
AC – Characteristics
(under recommended operating conditions, Reference Clock Frequency = 66 MHz)
Parameter
Min.
Typ.
Max.
Units
Input capacitance, any pin (@ 66 MHz)
1.5
3
pF
Serial Transmission Data Rate
1.32
Gbit/s
Serial Payload Data Rate
1.188
Gbit/s
Parallel Interface Data Rate
148.5
MByte/s
Serial Bit Width
757.6
ps
CMOS Output Rise / Fall Time (CL = 10 pF)
5
10
ns
Table 10: AC – Characteristics
