CC2550

PRELIMINARY Data Sheet (Rev.1.2)

SWRS039A

Page 51 of 54

28.4

Tray specification

CC2550 can be delivered in standard QLP 4x4 mm shipping trays.

Tray Specification

Package

Tray Width

Tray Height

Tray Length

Units per Tray

QLP 16

125.9 mm

7.62 mm

322.6 mm

490

Table 29: Tray specification

28.5

Carrier tape and reel specification

Carrier tape and reel is in accordance with EIA Specification 481.

Tape and Reel Specification

Package

Tape Width

Component

Pitch

Hole

Pitch

Reel

Diameter

Units per Reel

QLP 16

12 mm

8 mm

4 mm

13 inches

2500

Table 30: Carrier tape and reel specification

Ordering Information

Chipcon Part

Number

TI Part Number

Description

Minimum Order Quantity

(MOQ)

CC2550-RTY1

CC2550RTK

CC2550 QLP16 RoHS Pb-free 490/tray

490 (tray)

CC2550-RTR1

CC2550RTKR

CC2550 QLP16 RoHS Pb-free 2500/T&R

2500 (tape and reel)

CC2500-CC2550DK

CC2500_CC2550 Development Kit

CC2550EMK

CC2500 Evaluation Module Kit

Table 31: Ordering information

General Information

30.1

Document History

Revision

Date

Description/Changes

1.2

2006-06-28 Added figures to table on SPI interface timing requirements.

Added information about SPI read.

Updates to text and included new figure in section on arbitrary length configuration.

Added information that RF frequencies at n/2·crystal frequency (n is an integer number)

should not be used due to spurious signals at these frequencies .

Updates to text and included new figures in section on power-on start-up sequence.

Added information about how to check for PLL lock in section on VCO.

Better explanation of some of the signals in table of GDO signal selection.

Added section on wideband modulation not using spread spectrum under section on

system considerations and guidelines.

Added more detailed information on PO_TIMEOUT in register MCSM0.

Changes to ordering information.

1.1

2005-06-27 Updated TEST1 register default value. 26-27 MHz crystal range. Added matching

information. Added information about using a reference signal instead of a crystal.

1.0

2005-01-24 First preliminary data sheet release.

Table 32: Document history
