CC2550-RTY1 数据表(PDF) 17 Page - Texas Instruments |
|
|
|
|||||||||||||||||||||||||||||
CC2550-RTY1 数据表(HTML) 17 Page - Texas Instruments |
|
|
17 / 55 page  CC2550 PRELIMINARY Data Sheet (Rev.1.2) SWRS039A Page 17 of 54 The PATABLE is an 8-byte table that defines the PA control settings to use for each of the eight PA power values (selected by the 3-bit value FREND0.PA_POWER). The table is written and read from the lowest setting (0) to the highest (7), one byte at a time. An index counter is used to control the access to the table. This counter is incremented each time a byte is read or written to the table, and set to the lowest index when CSn is high. When the highest value is reached the counter restarts at 0. The access to the PATABLE is either single byte or burst access depending on the burst bit. When using burst access the index counter will count up; when reaching 7 the counter will restart at 0. The read/write bit controls whether the access is a write access (R/W=0) or a read access (R/W=1). If one byte is written to the PATABLE and this value is to be read out then CSn must be set high before the read access in order to set the index counter back to zero. Note that the content of the PATABLE is lost when entering the SLEEP state. 11 Microcontroller Interface and Pin Configuration In a typical system, CC2550 will interface to a microcontroller. This microcontroller must be able to: • Program CC2550 into different modes • Write buffered data • Read back status information via the 4-wire SPI-bus configuration interface (SI, SO, SCLK and CSn) 11.1 Configuration Interface The microcontroller uses four I/O pins for the SPI configuration interface (SI, SO, SCLK and CSn ). The SPI is described in 13 on page 13. 11.2 General Control and Status Pins The CC2550 has one dedicated configurable pin and one shared pin that can output internal status information useful for control software. These pins can be used to generate interrupts on the MCU. See Section 24 page 30 for more details of the signals that can be programmed. The dedicated pin is called GDO0. The shared pin is the SO pin in the SPI interface. The default setting for GDO1/SO is 3-state output. By selecting any other of the programming options the GDO1/SO pin will become a generic pin. When CSn is low, the pin will always function as a normal SO pin. In the synchronous and asynchronous serial modes, the GDO0 pin is used as a serial TX data input pin while in transmit mode. The GDO0 pin can also be used for an on-chip analog temperature sensor. By measuring the voltage on the GDO0 pin with an external ADC, the temperature can be calculated. Specifications for the temperature sensor are found in Section 4.5 on page 7. With default PTEST register setting (0x7F) the temperature sensor output is only available when the frequency synthesizer is enabled (e.g. the MANCAL, FSTXON and TX states). It is necessary to write 0xBF to the PTEST register to use the analog temperature sensor in the IDLE state. Before leaving the IDLE state, the PTEST register should be restored to its default value (0x7F). |
|
