EM62100
65 COM/132 SEG STN LCD Driver
Product Specification (V1.1) 09.13.2005
•••• 31
(This specification is subject to change without further notice)
A7
A6
A5
A4
A3
A2
A1
A0
Column Address
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
1
0
0
0
0
0
0
1
0
2
1
0
0
0
0
0
1
0
130
1
0
0
0
0
0
1
1
131
7.2.5 Read Status
RS
RDB
WRB
D7
D6
D5
D4
D3
D2
D1
D0
0
0
1
BUSY
ADC
ON/OFF
RESET
0
0
0
0
Busy:
the busy bit indicates whether the driver accepts instruction or not.
Busy=0: the driver will accept new instruction
Busy=1: no new instruction will be accepted
ADC:
ADC=0: reverse (column address 131-n
segment driver n)
ADC=1: normal (column address n
segment driver n)
ON/OFF: indicates the current status of the display
ON/OFF=0: display ON
ON/OFF=1: display OFF
Reset:
indicates whether the driver is executing a hardware or software reset or if it
is in normal operating mode.
Reset=0: normal operation
Reset=1: currently executing a reset instruction
7.2.6 Write Display Data
Writes an 8-bit data from the data bus into the display RAM. Since the column address
automatically increments by 1 after each write, the microprocessor can continue to
write data with multiple words.
RS
RDB
WRB
D7
D6
D5
D4
D3
D2
D1
D0
1
1
0
Write data
