EM62100

65 COM/132 SEG STN LCD Driver

Product Specification (V1.1) 09.13.2005

•••• 37

(This specification is subject to change without further notice)

(2) Static Indicator Register Set

This command sets two bits of data into the static indicator register and used to set

the static indicator into a blinking mode.

RS RDB WRB D7 D6 D5 D4 D3 D2 D1 D0 Hex

Setting

00H

OFF

01H

blinking at

≈ 1sec interval

02H

blinking at

≈0.5sec interval

03H

ON (constantly on)

7.2.20 Power Save (Compound Command)

The power save mode is entered when the display all points ON command is executed

while in the display OFF mode. The power save mode includes the sleep mode and the

standby mode. The sleep mode is entered when the static indicator is OFF, and the

standby mode is entered when the static indicator is ON. This mode is cleared by the

display all points OFF command.

The sleep mode operation stops all operations in the LCD display system, and as long

as there are no accesses from the MPU. In sleep mode operation, the oscillator circuit,

the LCD power supply circuit, and all LCD driver circuits are put on halt.

Release the Sleep mode using both Power Save OFF command (Display ON

command or Entire Display OFF command) and Set Indicator On command.

Static Indicator OFF

(D7-D0)=AC (Hex)

Static Indicator ON

(D7-D0)=AD (Hex)

(D7-D0)=X0~X3H (Hex)

1. Display OFF

(D7-D0)=AE (Hex)

2. Entire Display ON

(D7-D0)=A5 (Hex)

1. Display OFF

(D7-D0)=AE (Hex)

2. Entire display ON

(D7-D0)=A5 (Hex)

Sleep Mode

Stanby Mode

Normal Display Mode

(D7-D0)=A4 (Hex)

1. Normal Display Mode

(D7-D0)=A4 (Hex)

2. Static Indicator ON

(D7-D0)=AD (Hex)

(D7-D0)=X0~X3H (Hex)

Sleep Mode Cancel

Stanby Mode Cancel

X: don't care
