EM62100

65 COM/132 SEG STN LCD Driver

44 •

•••

Product Specification (V1.1) 09.13.2005

(This specification is subject to change without further notice)

7.3.1.2 Without instant built-in power supply circuit, after turning on the power

Turn ON the V

DD - VSS power, keeping the RESB pin = "L"

When power is stabilized

Release the reset state (RESB pin = "H")

Initialized state (Default)

Function setup by command input (User setup)

(17) Setting the built-in resistance radio

to regulate the V0 voltage

(18) Electronic volume control

Function setup by command input (User setup)

(16) Power control setting

This concludes the initialization

Function setup by command input (User setup)

(11) LCD bias setting

( 8) ADC selection

(15) Common output state selection

Power saver START (multiple commands)

Power saver OFF (multiple commands)
