EM62100
65 COM/132 SEG STN LCD Driver
6 •
•••
Product Specification (V1.1) 09.13.2005
(This specification is subject to change without further notice)
Coordinate
Coordinate
Pad No.
Pad Name
X
Y
Pad No.
Pad Name
X
Y
193
SEG41
1225.0
388.0
241
SEG89
-1175.0
388.0
194
SEG42
1175.0
388.0
242
SEG90
-1225.0
388.0
195
SEG43
1125.0
388.0
243
SEG91
-1275.0
388.0
196
SEG44
1075.0
388.0
244
SEG92
-1325.0
388.0
197
SEG45
1025.0
388.0
245
SEG93
-1375.0
388.0
198
SEG46
975.0
388.0
246
SEG94
-1425.0
388.0
199
SEG47
925.0
388.0
247
SEG95
-1475.0
388.0
200
SEG48
875.0
388.0
248
SEG96
-1525.0
388.0
201
SEG49
825.0
388.0
249
SEG97
-1575.0
388.0
202
SEG50
775.0
388.0
250
SEG98
-1625.0
388.0
203
SEG51
725.0
388.0
251
SEG99
-1675.0
388.0
204
SEG52
675.0
388.0
252
SEG100
-1725.0
388.0
205
SEG53
625.0
388.0
253
SEG101
-1775.0
388.0
206
SEG54
575.0
388.0
254
SEG102
-1825.0
388.0
207
SEG55
525.0
388.0
255
SEG103
-1875.0
388.0
208
SEG56
475.0
388.0
256
SEG104
-1925.0
388.0
209
SEG57
425.0
388.0
257
SEG105
-1975.0
388.0
210
SEG58
375.0
388.0
258
SEG106
-2025.0
388.0
211
SEG59
325.0
388.0
259
SEG107
-2075.0
388.0
212
SEG60
275.0
388.0
260
SEG108
-2125.0
388.0
213
SEG61
225.0
388.0
261
SEG109
-2175.0
388.0
214
SEG62
175.0
388.0
262
SEG110
-2225.0
388.0
215
SEG63
125.0
388.0
263
SEG111
-2275.0
388.0
216
SEG64
75.0
388.0
264
SEG112
-2325.0
388.0
217
SEG65
25.0
388.0
265
SEG113
-2375.0
388.0
218
SEG66
-25.0
388.0
266
SEG114
-2425.0
388.0
219
SEG67
-75.0
388.0
267
SEG115
-2475.0
388.0
220
SEG68
-125.0
388.0
268
SEG116
-2525.0
388.0
221
SEG69
-175.0
388.0
269
SEG117
-2575.0
388.0
222
SEG70
-225.0
388.0
270
SEG118
-2625.0
388.0
223
SEG71
-275.0
388.0
271
SEG119
-2675.0
388.0
224
SEG72
-325.0
388.0
272
SEG120
-2725.0
388.0
225
SEG73
-375.0
388.0
273
SEG121
-2775.0
388.0
226
SEG74
-425.0
388.0
274
SEG122
-2825.0
388.0
227
SEG75
-475.0
388.0
275
SEG123
-2875.0
388.0
228
SEG76
-525.0
388.0
276
SEG124
-2925.0
388.0
229
SEG77
-575.0
388.0
277
SEG125
-2975.0
388.0
230
SEG78
-625.0
388.0
278
SEG126
-3025.0
388.0
231
SEG79
-675.0
388.0
279
SEG127
-3075.0
388.0
232
SEG80
-725.0
388.0
280
SEG128
-3125.0
388.0
233
SEG81
-775.0
388.0
281
SEG129
-3175.0
388.0
234
SEG82
-825.0
388.0
282
SEG130
-3225.0
388.0
235
SEG83
-875.0
388.0
283
SEG131
-3275.0
388.0
236
SEG84
-925.0
388.0
284
NC9
-3325.0
388.0
237
SEG85
-975.0
388.0
285
COM32
-3375.0
388.0
238
SEG86
-1025.0
388.0
286
COM33
-3425.0
388.0
239
SEG87
-1075.0
388.0
287
COM34
-3475.0
388.0
240
SEG88
-1125.0
388.0
288
COM35
-3525.0
388.0
