FT600Q-FT601Q IC DatasheetDatasheet

Version 1.04

Document No.: FT_001118

Clearance No.: FTDI#424

Future Technology

Devices International

Ltd.

FT600Q-FT601Q IC

Datasheet

(USB 3.0 to FIFO Bridge)

The FT600/FT601 is a USB 3.0 to FIFO interface

bridge chip with the following advanced features:



Supports USB 3.0 Super Speed (5Gbps)/USB

2.0 High Speed (480Mbps)/USB 2.0 Full

Speed (12Mbps) transfer.



Supported

USB

Transfer

Type:

Control/Bulk/Interrupt



Up to 8 configurable endpoints (PIPEs).



Supports 2 parallel slave FIFO bus protocols

245 and FIFO mode, FT601 with 32 bit

parallel interface has a data bursting rate up

to 400MB/s.



Supports 4 IN channels and 4 OUT channels

on FIFO bus connectivity.



Built-in 16kB FIFO data buffer RAM.



Supports Remote Wakeup capability.



Supports multi voltage I/O: 1.8V, 2.5V and 3.3V.



Configurable GPIO support.



Internal LDO 1.0V regulator.



Integrated power-on-reset circuit.



User programmable USB descriptors.



Supports Battery Charging spec. BC1.2 battery charging

detection.



Available as FT600-16bit/FT601-32bit FIFO interface.



Industrial operating temperature range: -40 to 85⁰C.



Available in compact Pb-free QFN-76(32bit) and QFN-

56(16bit) packages (both RoHS compliant).
