Document No.: FT_000648

FT121 ENHANCED USB DEVICE CONTROLLER WITH SPI SLAVE IC

Datasheet Version 1.2

Clearance No.: FTDI#

312

OUT Buffer. Data sent from the USB host controller to FT121 via the USB data OUT endpoint is stored in

the OUT buffer. Data is removed from the OUT buffer to system memory under control of the parallel

interface block.

IN Buffer. Data from system memory is stored in the IN buffer. The USB host controller removes data

from the IN buffer by sending a USB request for data from the device data IN endpoint.

RESET Generator. The integrated Reset Generator cell provides a reliable power-on reset to the device

internal circuitry at power up. The RESET_n input pin allows an external device to reset the FT121.

SPI Controller Block. The SPI slave controller provides control and data interfaces between the external

MCU and internal registers and endpoint buffers. It supports 4-wire (default) or 3-wire SPI operation.

4.2 Interrupt Modes

The FT121 interrupt pin (INT_n) can be programmed to generate an interrupt in different modes. The

interrupt source can be any bit in the Interrupt Register, an SOF packet being received, or both. The

interrupt modes are selectable by two register bits, one is the SOF-only Interrupt Mode bit (bit 7 of Clock

Division Factor register), and the other is the Interrupt Pin Mode bit (bit 5 of Interrupt Configuration

Interrupt

mode

Bit SOF-only

Interrupt

Mode

Bit Interrupt

Pin Mode

Interrupt source

Any bit in Interrupt register

Any bit in Interrupt register and SOF

SOF only

Table 4.1 Interrupt modes

4.3 SPI Slave Interface

The SPI slave interface supports 4-wire (default) and 3-wire operation. In 4-wire operation the SPI

master will drive data on the MOSI pin and the SPI slave will drive data on the MISO pin. In 3-wire

operation both SPI master and SPI slave share the same data pin (MOSI pin becomes a bi-directional

pin). Upon power-on or hardware reset, the FT121 SPI slave interface is in 4-wire mode. The 3-wire

operation is enabled when a Set 3-wire command is issued to the FT121.

The SPI protocol will follow a command + data format where a command is transmitted after SS_n is

asserted and each subsequent byte will be a data byte. When all data bytes for this command are

completed the SS_n is de-asserted. This can be seen in Figure 4-1.
