FT121 ENHANCED USB DEVICE CONTROLLER WITH SPI SLAVE IC

Datasheet Version 1.2

Clearance No.: FTDI#

312

Future Technology Devices

FT121

(Enhanced USB Device

Controller with SPI Slave IC)

The FT121 is a USB generic interface

controller with the following advanced

features:



USB 2.0 Full Speed compatible



High performance USB device controller with

integrated SIE, endpoint buffer, transceiver

and voltage regulators



Fully integrated clock generation with no

external crystal required



Supports Serial Parallel interface (SPI) slave to

external microcontroller



Supports up to 8 bi-directional endpoints with

total 2k bytes endpoint buffer



Max packet size is 504 bytes for isochronous

endpoint

and

64

bytes

for

control/bulk/interrupt endpoint



Double

buffer

scheme

for

any

endpoint

increases data transfer throughput



Multiple interrupt modes to facilitate both bulk

and isochronous transfers



USB

Battery

Charger

detection

allowing

optimized charging profile



Integrated

DP

pull-up

resistor

for

USB

connection



Supports

bus-powered

or

self-powered

applications



VCC power supply operation at 3.3V or 5V



Internal 1.8V and 3.3V LDO regulators



VCC IO level range from 1.8V to 3.3V



Integrated power-on-reset circuit



UHCI/OHCI/EHCI host controller compatible



-40°C to 85°C extended operating temperature

range



Available in Pb-free TSSOP-16 and QFN-16

packages (RoHS compliant)
